Описание
Тип Online
Изходна мощност 1000 VA
Ефективна мощност 900 W
Тегло 12 кг

Виждате грешка в описанието или таблицата? Сигнализирайте ни!

(Single Phase Input / Single Phase Output) rackmount servers and other network devices

High Frequency Double Conversion "On-Line" Technology
True Sine Wave Output
Full microprocessor controlled
Wide Input Voltage Range
LCD Display
Output Power Factor: 0.8 - 0.9
Modular Design
Adjustable LCD Panel for Rack and Tower Applications
ECO Mode
Cold Start (Network and start the battery)
Short circuit, overload and lightning protection
Network / Fax / Modem Line Protection
Phase Neutral Reverse Connection Protection
Adjustable output Bypass
Additional battery Backup Time
Smart RS-232 communication port
SNMP card, USB, Dry Contact Card (optional)
Common Technical Service Support
ISO9001 and CE

INPUT
Voltage Range 200 ~ 290VAC at full load
Frequency Range 45 ~ 55Hz at 50Hz / 65Hz at 55 ~ 60Hz (auto-sensing)
Phase Single-Phase and Ground
Current thdi 0.98
Generator Input supports
Circuit breaker 7a
Input Socket C13-10 to IEC320
AC Power Cord C14-10 to IEC320

OUTPUT
Voltage 200/208/220/230 / 240VAC
Power factor 0.8-0.9
Voltage Accuracy ± 2%
Frequency (Network Mode) 46 ~ 54Hz (50Hz) / 56 ~ 64Hz (60Hz)
Frequency (Battery Mode) 50 / 60Hz ± 0.2Hz
Current Crest Ratio 3: 1
harmonic Distortion < 3% THD (Linear Load)300ms at 150%
Battery Mode 100% ~ 150% in 30sec. , > 150% in 300ms

Productivity
AC Mode Full load > 89%
Battery Mode Full load > 84%
ECO Mode Full load > 94%

Battery
battery Type PF 0.8 2 x 12V / 9Ah (24VDC)
Backup Time Estimated Time Remaining displayed on the LCD
Charging Time (90%) 5 hours
Charging Current (Max) 1.0
Charging Mode 3-stage charging
Protection Over Voltage / Over Current / Low Voltage
Battery Socket Modular Connectors

Transfer Time
NetworkBattery 0ms
NetworkBypass Продукт известен още и като Powerpack SE RT 1000 VA MU 01000 N 11 EAR 04, PowerpackSERT1000VAMU01000N11EAR04, Powerpack SE RT 1000VA (MU01000N11EAR04), PowerpackSE-RT1000VAMU01000N11EAR04, Powerpack SE-RT 1000VA (MU01000N11EAR 04)
