Fractal Design Meshify 2 Compact RGB Black TG Light FD-C-MES2C-06

Meshify 2 Compact RGB

The Meshify 2 Compact RGB is a high-performing case with a bold, stealth-inspired aesthetic. Its striking exterior features bolt-free, flush tempered glass, a fully removable top panel granting excellent interior access, and a front USB 3.1 Type-C port. The front nylon filter can be removed for extra airflow, letting the mesh front deal with filtering. Intelligent space utilization enables the Meshify 2 Compact to boast the performance and capacity of larger cases despite its remarkably compact mid-tower size, and the filtered airflow design makes cooling a breeze.

• Iconic angular mesh front provides filtered airflow with a bold, stealth-inspired aesthetic


• Versatile and space-efficient ATX form-factor design offers the performance and capacity of much larger cases


• Built in RGB controller on the front/top I/O with iconic Fractal Northern Lights effect

Specifications

•
  3.5"/2.5" Universal drive mounts

  2 (included)



•
  Dedicated 2.5" drive mounts

  4 (2 included)



•
  Expansion slots

  7



•
  Front interface

  1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, RGB control button (RGB Version only)



•
  Total fan mounts

  7x 120 or 4x 140 mm and 2x 120 mm



•
  Front fan

  3x 120 or 2x 140 mm, (3x Aspect 12 RGB PWM included)



•
  Top fan

  2x 120/140 mm



•
  Rear fan

  1x 120 mm, (1x Aspect 12 RGB PWM included)



•
  Bottom fan

  1x 120 mm (requires removal of HDD cage)



•
  Dust filters

  Top, front and bottom



•
  Fixed cable straps

  Yes



•
  Cable routing grommets

  Yes



•
  Captive thumbscrews

  HDD, SSD and PSU brackets



•
  Left side panel

  Tempered glass



•
  Right side panel

  Steel


Compatibility

•
  Motherboard compatibility

  ATX / mATX / Mini-ITX



•
  Power supply type

  ATX



•
  PSU max length

  165 mm (with HDD cage and front fan)



•
  GPU max length

  345 mm



•
  CPU cooler max height

  169 mm



•
  Front radiator

  Up to 360/280 mm



•
  Top radiator

  Up to 240 mm



•
  Rear radiator

  120 mm



•
  Bottom radiator

  120 mm (requires removal of HDD cage)



•
  Cable routing space

  17-28 mm


Dimensions

•
  Case dimensions (LxWxH)

  424 x 210 x 475 mm



•
  Case dimensions w/o feet/protrusions/screws

  412 x 210 x 455 mm



•
  Package dimensions (LxWxH)

  542 x 320 x 554 mm



•
  Net weight

  8.5 KG



•
  Gross weight

  9.8 KG



•
  Volume

  41 liters


Other

•
  Package contents

  Meshify 2 Compact RGB Case, User manual, Accessory box



•
  EAN

  7340172703693
