SILENCIO DESIGN

The Silencio’s minimalistic design cloaks its complexity. Design elements fine-tuned in form and function result in minimized noise and efficiently maintained system temperatures













SILENCIO TECHNOLOGY

Behind the outer panels are pieces of meticulously placed sound dampening material. The development of the Silencio was driven by Sorama’s Cam64—this allowed for the entire sound spectrum to be visually analyzed by source, resonance pattern, and frequency.

With the identification of peaks within certain frequency ranges, fine-tuning the Silencio for the dispersion of resonance was made possible, reducing the prominence of noise generated by system components. Every detail in design optimized the Silencio for thermal efficiency and silence, from the type of material used to its placement.









SEAMLESS TEMPERED GLASS OR SOUND-DAMPENED STEEL

Available with seamless tempered glass or a sound-dampened steel side panel, systems can be built for show or for stealth with the Silencio













VENTILATION

For an even higher demand for ventilation, the top panel’s Sound Dampening Cover can be removed for unrestricted ventilation. An optional dust filter for the top panel ventilation is included, allowing the top panel and front panel work in conjunction to cool the system.









REVERSIBLE STEEL DOOR

The steel front door features a reversible mounting system, capable of opening in either direction. To prevent vibrations, a softer, thicker material spans the steel structure in conjunction with a hinge system of magnets and rubber stompers.









SPECIFICATIONS

MODEL NUMBER:  MCS-S400-KG5N-S00 (TG)

SERIES:  Silencio Series

SIZE:  Mini Tower

AVAILABLE COLOR(S):  Black

MATERIALS:  Steel, Plastic, Tempered Glass, Sound Dampening Material

DIMENSIONS (L X W X H):  418mm x 210mm x 408mm (incl. Protrusions), 403.5mm x 210mm x 400mm (excl. Protrusions)

MOTHERBOARD SUPPORT:  Mini ITX, Micro ATX

EXPANSION SLOTS:  4

5.25" DRIVE BAYS:  1

3.5" DRIVE BAYS:  4

2.5" DRIVE BAYS:  4

I/O PANEL:  2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Headset Jack (Audio+Mic), 1x SD card reader

PRE-INSTALLED FANS - FRONT:  1x 120mm (PWM 800-1400 RPM)

PRE-INSTALLED FANS - REAR:  1x 120mm (PWM 800-1400 RPM)

FAN SUPPORT - FRONT:  2x 120/140mm

FAN SUPPORT - TOP:  1x 120/140mm, 2x 120/140mm (remove ODD cage)

FAN SUPPORT - REAR:  1x 120mm

RADIATOR SUPPORT - FRONT:  120mm, 140mm, 240mm, 280mm (remove & reinstall ODD bracket to mount 280mm radiator, may interfere with HDD mounted below ODD bracket)

RADIATOR SUPPORT - TOP:  120mm, 240mm (requires removal of ODD cage)

RADIATOR SUPPORT - REAR:  120mm

CLEARANCE - CPU COOLER:  Steel: 167mm, TG: 166mm

CLEARANCE - GFX:  319mm

CLEARANCE - PSU:  325mm (w/o front radiator & HDD cage), 140mm (HDD cage in backmost position)

CABLE ROUTING:  20mm

DUST FILTERS:  Top, Front, Bottom

POWER SUPPLY SUPPORT:  Bottom mount, ATX PS2
