Описание на продукта
Параметри на продукта
Производител
EDIMAX
Брой портове 10/100/1000 Mbit/s
8
Управляем
не
QoS
не
Параметри на продукта
Производител
EDIMAX
Брой портове 10/100/1000 Mbit/s
8
Управляем
не
QoS
не
Описание на продукта
Complies with the IEEE 802.3 , IEEE 802.3u and IEEE 802.3ab standards.
Smart Green Ethernet technology to reduce power consumption 30%~50%.
Supports Auto-MDI/MDI-X, full/half duplex modes and auto-negotiation.
Supports flow control , Non-blocking and Jumbo Frame.
SMART-GREEN ETHERNET AND GIGABIT-SPEEDS
ES-5800G is Edimax’s new, smart-green Ethernet switch with gigabit speed that lessens energy-wastage to increase energy-efficiency. No more sluggish or failed, large-file transfer because this switch facilitates rapid, large-file transfers as well. ES-5800G is the ideal, energy-saving switch integrated with eight 10/100/1000Mbps Gigabit ports. It is designed to meet the increased demands of transferring large files speedily across networks. The switch detects the length of the Ethernet cable connection and automatically supplies the right amount of energy. It also reduces power consumption when ports are idle.
SUPPORTS FULL-WIRE-SPEED AND FLOW CONTROL
Enjoy guaranteed, quick data transfers with ES-5800G. It creates a high-speed Gigabit network, and users benefit from its enhanced performance and reliability. The ES-5800G complies with IEEE802.3, IEEE802.3u and IEEE802.3ab standards. Using non-blocking switching architecture, your network is equipped with full-wire speed connections. It activates flow control for full-duplex mode and back pressure for half-duplex mode that ensure reliable data transfers and help prevent data loss.
SUPPORTS JUMBO FRAME
The ES-5800G supports jumbo frame, which allows you to extend the Ethernet frame size to a maximum of 9600 bytes to increase data rates. This cost-efficient switch is the best choice for small office/home office needs.
SUPPORTS AUTO-MDI/MDI-X
The ES-5800G easy plug and play installation comes with auto-MDI/MDI-X support. Use either a straight-through or cross-over Ethernet cable and connect 10, 100 and 1000 Mbps devices into ES-5800G, and the switch will automatically detect suitable cable and device speeds for peak performance.
HARDWARE INTERFACE
8 x 10/100/1000Mbps Ethernet Ports
LED Indicators: Power and Link/Activity
FUNCTIONS
Jumbo Frame (9K Byte)
Non-Blocking
Store-and-Forward architecture
Full wire speed filtering
Auto-MDI/MDI-X and auto learning
A uto -negotiation
POWER ADAPTER
DC 12V, 1A
STANDARD
IEEE802.3, IEEE802.3u and IEEE802.3ab
IEEE802.3x
HUMIDITY & TEMPERATURE
10-95% (Non-condensing)
0~40 Degree Celsius
MEMORY BUFFER
1M Bits
MAC Address
4K
DIMENSION
157 x 78 x 26 mm
CERTIFICATIONS
CE, FCC
Manufacturer link
Smart Green Ethernet technology to reduce power consumption 30%~50%.
Supports Auto-MDI/MDI-X, full/half duplex modes and auto-negotiation.
Supports flow control , Non-blocking and Jumbo Frame.
SMART-GREEN ETHERNET AND GIGABIT-SPEEDS
ES-5800G is Edimax’s new, smart-green Ethernet switch with gigabit speed that lessens energy-wastage to increase energy-efficiency. No more sluggish or failed, large-file transfer because this switch facilitates rapid, large-file transfers as well. ES-5800G is the ideal, energy-saving switch integrated with eight 10/100/1000Mbps Gigabit ports. It is designed to meet the increased demands of transferring large files speedily across networks. The switch detects the length of the Ethernet cable connection and automatically supplies the right amount of energy. It also reduces power consumption when ports are idle.
SUPPORTS FULL-WIRE-SPEED AND FLOW CONTROL
Enjoy guaranteed, quick data transfers with ES-5800G. It creates a high-speed Gigabit network, and users benefit from its enhanced performance and reliability. The ES-5800G complies with IEEE802.3, IEEE802.3u and IEEE802.3ab standards. Using non-blocking switching architecture, your network is equipped with full-wire speed connections. It activates flow control for full-duplex mode and back pressure for half-duplex mode that ensure reliable data transfers and help prevent data loss.
SUPPORTS JUMBO FRAME
The ES-5800G supports jumbo frame, which allows you to extend the Ethernet frame size to a maximum of 9600 bytes to increase data rates. This cost-efficient switch is the best choice for small office/home office needs.
SUPPORTS AUTO-MDI/MDI-X
The ES-5800G easy plug and play installation comes with auto-MDI/MDI-X support. Use either a straight-through or cross-over Ethernet cable and connect 10, 100 and 1000 Mbps devices into ES-5800G, and the switch will automatically detect suitable cable and device speeds for peak performance.
HARDWARE INTERFACE
8 x 10/100/1000Mbps Ethernet Ports
LED Indicators: Power and Link/Activity
FUNCTIONS
Jumbo Frame (9K Byte)
Non-Blocking
Store-and-Forward architecture
Full wire speed filtering
Auto-MDI/MDI-X and auto learning
A uto -negotiation
POWER ADAPTER
DC 12V, 1A
STANDARD
IEEE802.3, IEEE802.3u and IEEE802.3ab
IEEE802.3x
HUMIDITY & TEMPERATURE
10-95% (Non-condensing)
0~40 Degree Celsius
MEMORY BUFFER
1M Bits
MAC Address
4K
DIMENSION
157 x 78 x 26 mm
CERTIFICATIONS
CE, FCC
Manufacturer link
