Q Acoustics 3020i

Q Acoustics 3020i



Our 3020i bookshelf speakers have an award-winning heritage, and with even more technological and aesthetic enhancements, they're unbeatable for the price. The 5" and 0.9" precision drivers deliver beautiful, room-filling sound without sacrificing aesthetics, so you get stunning sound. The 3020i speakers have a slightly taller and deeper cabinet, which allows them to gain an extended low-frequency response for an impressively large-scale sound. With decoupled tweeters, the woofer is able to perform with reduced interference. These speakers also have P2P (point-to-point) bracing that makes the enclosures exceptionally rigid, improving the focus of the stereo image and giving the soundstage more accuracy than ever before.





Bigger, Bolder Sound From The Q 3020i

The Q 3020i  builds on the success of its multi award winning predecessor. Boasting 125mm (5 in) and 22mm (0.9 in) precision drivers, the Q 3020i speakers deliver deep bass and room-filling sound. The Q 3020i maintain the same acoustically optimal front profile but have been made slightly taller and deeper giving an overall cabinet size increase of 25%. This increased internal volume has enabled the Q 3020i to gain an extended low frequency response from the ported design so that more-than-ever the smaller enclosures in the range belie their diminutive stature with an impressively large-scale sound.

The Q 3020i speakers can be shelf-mounted on compliant, pre-fitted rubber feet, stand-mounted or wall-mounted on optional, dedicated stands and brackets ensuring the Q 3020i fit seamlessly and fill your chosen listening room with bold, beautiful sound.





High-Frequency Driver Unit

3000i Series tweeters are decoupled from the baffle via a compliant suspension system. Vibrations from the woofer, which can impair the performance of the tweeter are isolated allowing the tweeter to perform with dramatically reduced interference.

New Low Profile Binding Posts For Easy Room Positioning



Conventional terminal panel cut-outs have been removed, giving greatly improved structural integrity to the enclosures and new low profile binding posts have been incorporated with sockets deep enough to accept 4mm (0.16 in) Banana Plugs. The speaker can be positioned very close to a rear wall even when banana plugs rather than spades or bare wires are used.



Specifications

Crossover Frequency2.4 kHzDimensions275 x 170 x 265 mm (10.8 x 6.7 x 10.4 in) cabinet
278 x 170 x 281 mm (10.9 x 6.7 x 11.0 in) overallEnclosure Type2-Way ReflexFrequency Response(+3 dB, -6 dB) 64Hz-30kHzImpedance6 OhmMinimum Impedance4 OhmPower Input25 - 75WAV Receiver (2 ch. driven)50 - 75WSensitivity88dB Tweeter22 mm (0.9 in)Weight4.8kg
