APC Easy UPS BVX 2200VA 230V IEC

  ManufacturerAPCManufacturer Part NoBVX2200LI Marketing DescriptionEasy UPS provides power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments. Product Features

• Automatic Voltage Regulation (AVR)
  Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
• Audible alarms
  Provides notification of changing utility power and UPS power conditions.
• LED indicators
  Provide easy-to-read status of the unit and utility power conditions.
• Battery and surge protected outlets
  Back up and protect your hardware and data during power outages, surges and spikes.
• Battery backup and surge protection
  Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.
• Advanced safety features
  Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.
• Battery failure notification
  Provides early-warning fault analysis on batteries enabling timely preventive maintenance.
• Intelligent battery management
  Maximizes battery performance, life, and reliability through intelligent, precision charging.

GeneralDevice TypeUPS - externalColourBlackPower DeviceUPS TechnologyOff-lineInput VoltageAC 220-240 VInput Voltage RangeAC 140 - 300 VFrequency Provided50/60 HzFrequency Required50/60 HzInput Connectors1Power Output Connectors Details6 x power IEC 60320 C19Output VoltageAC 230 V ± 10% - 50/60 HzPower Capacity1200 Watt / 2200 VAOutput WaveformStepped approximation to a sinewaveSurge Energy Rating273 JoulesCircuit ProtectionCircuit breakerBatteryQuantity2TechnologyLead AcidVoltage Provided12 VCapacity9 AhRecharge Time8 hoursTransfer Time6 msMiscellaneousCables IncludedPower cable - external - 1.22 mFeaturesAudible alarm, Automatic Voltage Regulation (AVR)Compliant StandardsCB, IEC 62040-2, EN 62040-2, IP20, IEC 62040-1, EN 62040-1Manufacturer WarrantyService & SupportLimited warranty - replace or repair - 2 yearsEnvironmental ParametersMin Operating Temperature0 °CMax Operating Temperature40 °CHumidity Range Operating0 - 95% (non-condensing)Sound Emission40 dBADimensions & WeightWidth14 cmDepth39 cmHeight19 cmWeight12.2 kgDimensions & Weight (Shipping)Shipping Width23.5 cmShipping Depth49.5 cmShipping Height29.7 cmShipping Weight13.2 kgTechnical data provided by third party. We assume no liability for errors within these data.
