Arctic Freezer 4U-M Rev. 2
Versatile Multi-Compatible Server Cooler
The Freezer 4U-M Rev. 2 is compatible with a wide range of Intel and AMD server processors, including Intel sockets LGA4189 and LGA4677, as well as AMD sockets SP6, sTR5, SP3, TR4, sTRX4, and sWRX8. With a power consumption of only 2.88 watts while delivering high cooling performance, it emphasizes energy efficiency and is ideal for cooling high-performance processors with up to 64 cores and a TDP of up to 350 watts.
RAM Compatibility and Clearance
The Freezer 4U-M Rev. 2 offers a generous 53 mm of clearance for memory, allowing the use of RAM modules with moderate heatsinks. This space facilitates efficient airflow and ensures compatibility with various types of RAM.
Compact Design and Dual Socket Compatibility
With an optimised installation height of only 145 mm, it fits into both classic 4U server racks and most consumer 4U cases available on the market. The Freezer 4U-M Rev. 2 features a compact design with dimensions of just 156 x 124 mm. This also makes it suitable for dual-socket motherboards. To adjust the airflow direction if required, the fans can be easily swapped over.
Powerful Fans in Push-Pull Configuration
The installed PWM fans benefit from all the advantages of the award-winning P series. Designed for static pressure, the fans are ideal for the Freezer 4U-M Rev. 2's high fin density and provide efficient heat dissipation in push-pull mode, even in power-hungry applications. Especially office workstations benefit from the quiet fans. The dual configuration also allows for inherent redundancy and protects the system from total shutdown caused by heat.
Designed for continuous operation
Both fans of the Freezer 4U-M Rev. 2 are equipped with dual ball bearings, which allows for 24/7 continuous operation without the slightest compromise in performance. This type of bearing is much more resistant to contamination and wear caused by high temperatures than conventional sleeve bearings or Fluid-Dynamic bearings and is therefore the perfect choice if you want to ensure fault-free continuous operation.
Tech Specs
General Specifications
Thermal Compound
ARCTIC MX-6 0.8 g Syringe incl.
Operating Ambient Temperature
0–40 °C
Dimensions
124 (L) x 156 (W) x 145 (H) mm
Weight
1332 g
Compatibility
Intel
LGA4710, LGA 4677, LGA 4189
AMD
SP6, sTR5, SP3, TR4, sTRX4, sWRX8
Ampere
*LGA4926 (separate mounting kit required) *
Server Rack Unit
4U & up
Heatsink Specifications
Heat Pipe
Direct Touch, Ø 6 mm x 8
Number of Fins
57
Fin Material
Aluminium
Fan Specifications
Fan
2 x 120 mm PWM Fans
Fan Speed
400–2300 rpm, PWM Controlled
Connector
4-Pin Plug
Cable Length
200 mm
Bearing
Dual Ball Bearing
Noise Leve
40 dBA
Air Flow
71.90 cfm | 122.16 m³/h
Static Pressure
3.30 mmH2O
Current | Voltage
0.12 A | 12 V DC
Startup Voltage
8 V DC
