ASUS PRO WS WRX90E-SAGE SE

Доставка на този тип поръчки:
Продукта се поръчва специално за клиента, от склад извън България.
В зависимост от типа и теглото на продукта, е възможно да бъде изискано предварителното му заплащане по банка, с карта или в брой в магазина.
Срока за доставка е 2-5 дни след получено потвърждение на поръчката.


MB ASUS PRO WS WRX90E-SAGE SE (AMD. sTR5. DDR5. EEB)

ASUS Pro WS WRX90E-SAGE SE MotherboardASUS Pro WS WRX90E-SAGE SE Motherboard:Manufacturer : ASUSManufacturer Part No : 90MB1FW0-M0EAY0Marketing DescriptionThe AMD sTR5 EEB workstation motherboard features 7 PCIe 5.0 x16 slots, with support for multi-GPU. It has a robust power-stage design of 32+3+3+3, making it ready for CPU and memory overclocking. The motherboard also offers 4 PCIe 5.0 M. 2 slots, dual 10 Gb LAN, and a PCIe Q-Release slim. Product Features

• Ultrafast connectivity
  Features seven PCIe 5.0 x16 slots, dual 10 Gb LAN ports, four M. 2 slots, two rear USB4 40Gbps Type-C and SlimSAS NVMe support.
• Robust power and thermal design
  32+3+3+3 power stages with two 8-pin power connectors for the CPU, massive VRM cooling, chipset and M. 2 heatsinks with active fans, and M. 2 thermal pad.
• PCIe Q-release slim
  Remove the graphics card by directly pulling it up, instead of pressing a PCIe latch.
• Trusted stability
  Validated for extensive compatibility with advanced technologies, an expansive QVL list, and tested for 24/7 operation.

GeneralProduct Type : Motherboard - SSI EEBProcessor : AST2600Chipset Type : AMD WRX90Processor Socket : Socket sTR5Max Processors Qty : 1Compatible Processors : (supports Ryzen Threadripper PRO 7000WX Series/ 7000 Series)Supported RAMTechnology : DDR5Supported RAM Integrity Check : ECCRegistered or Buffered : RegisteredFeatures : Quad channel memory architectureAudioType : HD Audio (6-channel)Audio Codec : Realtek ALC1220PCompliant Standards : High Definition AudioLANNetwork Interfaces : Gigabit EthernetExpansion / ConnectivityExpansion Slots : 1 x CPU
8 x DIMM 288-pin
6 x PCIe 5.0 x16
1 x PCIe 5.0 x16 (x8 mode)
2 x M. 2 socket (2242/2260/2280/22110 M. 2 Key M slot)
2 x M. 2 socket (2242/2260/2280 M. 2 Key M slot)Storage Interfaces : SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5
PCIe 5.0 -connectors: 4 x M. 2
PCIe 4.0 -connectors: 2 x SlimSASInterfaces : 1 x VGA
2 x Mini DisplayPort
6 x USB 3.2 Gen 2
2 x USB4
1 x USB 2.0
2 x LAN (10Gigabit Ethernet)
1 x microphone - mini-jack
1 x audio line-out - mini-jack
1 x LAN (Gigabit Ethernet)Internal Interfaces : 4 x USB 2.0 - header
2 x USB 3.2 Gen 1 - header
1 x USB-C 3.2 Gen 2x2 - header
1 x audio - header
1 x SPI - headerPower Connectors : 24-pin main power connector, 2 x 8-pin ATX12V connectors, 2 x 8-pin PCI Express power connector, 2 x 8-pin PCI Express to CPU power connectorFeaturesBIOS Features : UEFI BIOSSleep / Wake Up : Wake on LAN (WOL), wake on PMEHardware Features : ASUS Q-Design, ESD Guards, Q-DIMM, ASUS EZ DIY, Q-LED, Q-Slot, CrashFree BIOS 3, ASUS DIGI+ VRM, Q-Code, Clear CMOS Button, ASUS Stainless Steel Back I/O, overcurrent protection, LANGuard, overvoltage protection, ASUS SafeSlot, ASUS 5X Protection III, ASUS SafeDIMM, M. 2 heatsink, pre-mounted I/O shield, ASUS ProCool II, M. 2 Q-Latch, PCIe Slot Q-Release, BIOS FlashBack button, BIOS FlashBack LED, VRM heatsink with fan, steel backplate, M. 2 heatsink backplate, Q-Connector, 32+3+3+3 Phase Power DesignMiscellaneousIncluded Accessories : Thermistor cable, Q-Connector, M. 2 Q-Latch, M. 2 Key E screw package, AMI licence sticker, 4 x M. 2 rubber packageCables Included : 4 x Serial ATA cable
2x 8-pin PCIe to single 8-pin CPU convertor
1 x 24-pin power cable (Y-cable)
2 x Mini DisplayPort cableSoftware Included : ASUS CPU-Z, ASUS Control Center Express, Armoury Crate, ASUS Fan Xpert 4, Norton 360 Deluxe (60 days trial), Adobe Creative Cloud (free trial), WinRAR (40 days trial)Width : 30.5 cmDepth : 33 cmTechnical data provided by third party. We assume no liability for errors within these data.
