AUSU ROG Strix 850W Gold PSU Power Supply

  ManufacturerASUSManufacturer Part NoROG-STRIX-850G Marketing DescriptionThe ROG Strix Series PSUs bring cooling and premium components together for an ultra-quiet high-performance product aimed at core gamers. Below the surface, low RDS (on) MOSFETs and premium Japanese capacitors take on power delivery with ease. The result is an incredibly quiet and efficient power supply with the reserves to handle the most intense gaming scenarios. Product Features

• Let it sink in
  The integrated ROG heatsinks have 2x more volume than traditional designs, resulting in significantly lower temperatures inside ROG Strix Series PSUs. This extends the lifespan of components and allows 0dB operation for a longer duration than standard designs. The heatsinks are so effective that fan noise stays whisper quiet, even under full load.
• Better, faster, stronger
  Originally developed for top-end ROG graphics cards, Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure.
• Quiet intelligence
  An onboard controller brings the 135 mm fan to a standstill when thermal design power (TDP) is below 40%, letting you enjoy light gaming in relative silence. Above 40% TDP, the fans automatically start up again.
• Plug in
  Each model comes with fully modular 24-pin, 6+2-pin PCI-e, and 8-pin CPU cables that have embedded capacitors to reduce voltage ripple. And if you'd like to add a dash of color to your build, the included CableMod coupon will set you on your way towards next-level customization.

GeneralDevice TypePower supply - internalSpecification ComplianceATX12VPSU Form FactorATXPower DeviceInput VoltageAC 100-240 VPower Output Connectors Details1 x power 24 pin ATX with detachable 4 pin section

2 x power 8 pin +12V with detachable 4 pin section

6 x 8 pin PCI Express power with detachable 2 pin section

8 x 15 pin Serial ATA power

6 x 4 PIN internal powerOutput Voltage+3.3, +5, ±12 VPower Capacity850 WattOutput Current+3.3V - 20 A

+5V - 20 A

+12V - 70 A

-12V - 0.3 A

+5VSB - 3 AModular Cable ManagementYes80 PLUS Certification80 PLUS GoldMiscellaneousIncluded Accessories2 x ROG badges, ROG logo magnet, 3 x ROG labelsCooling System135 mm fanFeaturesOverheat protection, over current protection, over voltage protection, overpower protection, short-circuit protection, dual ball bearing cooling fan, fully modular, ROG heatsink, Axial-tech fan design, 0db TechnologyCompliant StandardsRoHSManufacturer WarrantyService & SupportLimited warranty - 10 yearsDimensions & WeightWidth15 cmDepth16 cmHeight8.6 cmWeight1.825 kgDimensions & Weight (Shipping)Shipping Weight3.48 kgTechnical data provided by third party. We assume no liability for errors within these data.
