Cudy FS1006P

Cudy FS1006P

● Complies with IEEE802.3af/at Standard

● Supports PoE power up to 32W for each PoE port

● Auto detect non PoE device and PoE device

● Power prioritization guarantee power supply of key nodes

● CCTV/VLAN mode switch, remote power and data up to 250m

● Supports IEEE802.3 x full duplex / half duplex flow control

● Supports storage and forward for Data exchange





4-Port PoE + 2-Port Uplink

●  10/100 Mbps Ethernet Ports

●  IEEE 802.3af/802.3at compliant

●  60W total PoE Power supply.

●  Ideal for installations of 4 PoE/PoE+ devices

●  Pin assignment: alternative 1/2 (+), 3/6 (-).

Rack Mount & Wall Mount & Desktop

●  Provide a variety of installation methods for easy deployment in any environment

●  Support Wall mount installation

●  Support Desktop installation

Heat Dissipation

●  Made of high-quality metal case, sturdy and durable with long service life, provide better heat dissipation, suitable for most environment.

●  Venting holes help to dissipate heat quickly and ensure stable product operation

Texas Instruments PoE chipset inside

●  Texas Instruments TPS POE chipset and Realtek switch chipset ensure High performance and stable operation of the product.

Auto-sensing

●  Port-Power-Prioritization technology ensure continuous power supply of key nodes.

●  Auto-sensing technology delivers up to 32W to an 802.3at PoE+ device with backwards compatibility for 802.3af PoE (15.4W) devices

Lightning protection

●  Electrostatic standard: contact 6KV, air 8KV

●  MTBF > 50000 hour



Specifications:

Model
FS1006P

PoE standard
IEEE802.3af/at

Interface
6*10/100Mbps RJ45 port

key function
CCTV

PoE port
1-4

PoE Total
60W

Power supply
65W

RJ45 PoE power supply
Mode A Anode1/2 Cathode3/6

PoE output-port
Max 32W

Indicator
PWR, LNK/ACT, PoE

Network media
10BASE-T: UTP category 3, 4, 5 cable(≤100m)；100BASE-TX: UTP category 5, 5e cable(≤100m)

MAC Address Table
2K, Automatic study, automatic updates

jumbo frame
1528K Bytes

Packet buffer
768K bit

Transfer Mode
Store-and-forward

Packet forwarding rate
0.89Mpps

Bandwidth
1.2Gbps

Fan
Fanless

Device Dimension
168*93*32mm

Machine weight
50000 hour

Electrostatic standard
Contact 4KV, air 6KV
