Dahua 8-channel DVR XVR7108HE-4KL-X

Dahua XVR7108HE-4KL-X

8 Channel Penta-brid 4K Mini 1U Digital Video Recorder
H. 265+/H. 265 dual-stream video compression
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Supports 16 channels of IPC access, each channel up to 8MP input; Max 64Mbps Incoming Bandwidth
IoT & POS functionalities
Smart Search and Intelligent Video System

System

Main Processor
Embedded Processor

Operating System
Embedded LINUX

Video and Audio
Analog Camera Input
8 Channel, BNC
HDCVI Camera
4K, 6MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
AHD Camera
5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps
TVI Camera
5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps
CVBS Camera
PAL/NTSC

IP Camera Input
8+8 Channel, each channel up to 8MP

Audio In/Out
8 Channel Input, 1 Channel Output, RCA

Two-way Talk
Reuse audio in/out, RCA

Recording
Compression
H. 265+/H. 265/H. 264+/H. 264

Resolution
4K, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, 960H, D1, CIF

Record Rate
Main stream: 4K(1~15fps); 6MP(1~20fps); 5MP(1~20fps); 4MP/3MP/1080P/720P/960H/D1/CIF (1~25/30fps)
Sub steram:960H(1~15fps);
D1/CIF(1~25/30fps)

Bit Rate
32Kbps ~ 8192Kbps Per Channel

Record Mode
Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop

Record Interval
1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec

Audio Compression
AAC(only for the 1st channel), G. 711A, G. 711U, PCM

Audio Sample Rate
8KHz, 16 bit Per Channel

Audio Bit Rate
64Kbps Per Channel

Display
Interface
1 HDMI, 1 VGA

Resolution
HDMI:3840×2160, 2560×1440,  1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720

Multi-screen Display
When IP extension mode not enabled: 1/4/8/9
When IP extension mode enabled: 1/4/8/9/16

OSD
Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Network
Interface
1 RJ-45 Port (1000M)

Network Function
HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G,  UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, IP Search (Supports Dahua IP camera, DVR, NVS, etc. )

Max. User Access
128 users

Smart Phone
iPhone, iPad, Android

Interoperability
ONVIF 16.12, CGI Conformant

Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis

Alarm input
8

Relay Output
3

Playback and Backup

Playback
1/4/9

Search Mode
Time /Date, Alarm, MD and Exact Search (accurate to second)

Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom

Backup Mode
USB Device/Network

Storage
Internal HDD
1 SATA Port, up to 10TB capacity for each disk

eSATA
N/A

Auxiliary Interface

USB
2 USB Ports (1 USB 2.0 , 1 USB 3.0)

RS232
N/A

RS485
1 Port, for PTZ Control

Electrical
Power Supply
DC12V/2A

Power Consumption
(without HDD)
