Dahua IP видеорекордер Dahua VIGI NVR1108H-W, 8 канален, H. 265+/H. 265/ H. 264+/H. 264, 1x SATA (до 10TB), Wi-Fi, 2x USB 2.0, 2x RJ-45, 1x HDMI, 1x VGA (NVR1108H-W)

Dahua VIGI NVR1108H-W

• 8-Channel Live View and 4K HDMI Video Output
• Built-in Routering Module and Support Wireless Pairing*
• Up to 8-ch @ 2MP (25fps) / 4-ch @ 4MP (25fps) Decoding Capability
• 8-Channel Synchronous Playback†
• 80 Mbps Incoming Bandwidth and 60 Mbps Outgoing Bandwidth
• 1 SATA Interface (up to 10 TB) **
• H. 265+ Compression Technology
• HDMI and VGA Simultaneous Output
• Remote Monitoring







Video and AudioIP Video Input 8-ChannelIncoming Bandwidth 80 MbpsOutgoing Bandwidth 60 MbpsHDMI Output Resolution 1 Channel, Resolution: 3840 ×2160/30Hz, 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60HzVGA Output Resolution 1 Channel, Resolution: 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60HzVideo Output Mode HDMI/VGA Simultaneous OutputMulti-View Display 1/4/6/8DECODINGAudio Compression G. 711A/G. 711U/G. 726Video Compression H. 265+/H. 265/ H. 264+/H. 264Record Resolution 8 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIFSynchronous Playback 8-Channel†Capability25fps:
2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP

30fps:
4-ch @ 3MP, 2-ch @ 5MPRecord ManagementRecord ModeManual Recording
Scheduling Recording
Motion Detection RecordingPlayback ModeInstant Playback
Regular Playback
Tag Playback
Event PlaybackBackup ModeRegular Backup
Video Clip BackupPlayback FunctionPlay
Pause
Stop
Fast Forward
Fast Backward
Play By Frame
Video Clip
Export Clip
Lock Recording
Audio On/OffМРЕЖАProtocol UPnP (Plug and Play), NTP (Network Timing), SMTP, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARPMobile Phone Access Android, iOSWeb Browser Chrome (57+), Firefox (52+), Edge (91+)Interoperability ONVIF Profile S/T/G, CGIБЕЗЖИЧНИ ХАРАКТЕРИСТИКИStandards and Protocols IEEE 802.11b/g/nWiFi ChannelsUN: 1-13
US: 1-11Wireless NameSSID Configuration
RadioNetwork Switch YesЧестота 2.4 GHzAuto Wireless Channel N/AWireless Statistics N/AThroughput Monitoring N/ARadio BandwidthAuto: Yes
20M: Yes
40M: YesWireless Rate 300Mbps(802.11n), 2 × 2 MIMOWireless Security WPA-PSK/WPA2-PSKExternal InterfaceNetwork Interface1× RJ-45 10/100 Mbps Self-Adaptive WAN/LAN Ethernet Interface
1× RJ-45 10/100 Mbps Self-Adaptive LAN Ethernet InterfaceUSB Interface 2× USB 2.0Audio Interface 1-ch RCA Input; 1-ch RCA OutputAlarm In/Out N/ASerial Interface N/APower 1× DC JackReset Button 1Speaker 1; Real-time Audio Output without Needing Peripherals. eSATA N/AHDMI 1VGA 1HARD DISKSATA 1 SATA InterfaceCapacity Up to 10 TB Capacity for Each HDD**AlarmGeneral AlarmMotion Detection
Video Tampering
Scene Change Detection
Line-Crossing Detection
Intrusion Detection
Region Entering Detection
Region Exiting Detection
Loitering Detection
Object Abandoned/Removal Detection
Vehicle Detection
Human Detection
Abnormal Sound Detection
Smart Frame
Note: The alarm function requires the use of a camera.
 Anomaly AlarmVideo Loss
Offline and IP Conflict
Disk Exception
Login Exception
Note: The alarm function requires the use of a camera. Alarm LinkageRecording
White Light Alarm
Log
Audible Alarm
Note: The alarm function requires the use of a camera. ОБЩИ ХАРАКТЕРИСТИКИStorage Temperature -40–70 °CStorage Humidity 10%~90% RH Non-CondensingСъдържание на пакетаVIGI Network Video Recorder
Power Adapter
HDD Screws
Mouse
Quick Installation GuideWorking TemperatureNVR: -10–55 °C
Power Adapter: 0–40 °CWorking Humidity 10%~90% RH Non-CondensingРазмери (Ш x Д x В ) Excluding Antennas: 7.9 × 7.9 × 1.7 in (200.3 × 200.3 × 43 mm)Външно захранване DC 12V/2ANet Weight 0.5 kgGross Weight 1.0 kgMax. Power Consumption5.7 W (Without Disk)
16.3 W (Without Disk)AntennaQuantity: 2
Type: 2.4GHz Welded Non-detachable Antenna
Gain: 5.3dBi
Radio Frequency Transmit Power: 16dBm
Length: 198.8 mm for Long Side and 189 mm for Short Side
