Dahua IPC-HDW3549H-AS-PV-0280B-S5

Dahua IPC-HDW3549H-AS-PV-0280B-S5



SPECIFICATION

Standard: IPResolution: 2960 x 1668  - 5 Mpx ,
2880 x 1620  - 4.6 Mpx ,
2688 x 1520  - 4 Mpx ,
2560 x 1440  - 4 Mpx ,
2048 x 1536  - 3 Mpx ,
2304 x 1296  - 3 Mpx ,
1920 x 1080  - 1080p ,
1280 x 960  - 1.3 Mpx ,
1280 x 720  - 720pSensor: 1/2.7 " Progressive Scan CMOSLens: 2.8 mmView angle: 106 °Range of IR illumination: ≤ 30 mWhite light LED illuminator range: ≤ 30 mImage compression method: H. 265+ / H. 265 / H. 264+ / H. 264 / MJPEGMemory card slot: Micro SD card support up to 256GBAlarm inputs / outputs: 1 / 1 Audio:

• Microphone built-in : 2 pcs,
• Audio input,
• Audio output,
• Speaker built-in,
• Bi-directional audio streaming support,
• Audio detection,
• Compliance with the AAC standard

Main stream frame rate: 25 fps @ 5 MpxNetwork interface: 10/100 Base-T (RJ-45)WEB Server: Built-inMax. number of on-line users: 20 Mobile phones support:

Port no. : 37777 or access by a cloud (P2P)

• Android: Free application DMSS
• iOS (iPhone): Free application DMSS

Default IP address: 192.168. 1.108 Default admin user / password: admin / -
The administrator password should be set at the first startWeb browser access ports: 80, 37777 PC client access ports: 37777 Mobile client access ports: 37777 Port ONVIF: 80 RTSP URL: rtsp://admin:hasł[email protected]. 1.108:554/cam/realmonitor?channel=1&subt ype=0 - Main stream
rtsp://admin:hasł[email protected]. 1.108:554/cam/realmonitor?channel=1&subt ype=1 - Sub streamIntelligent image analysis:

• crossing the line (tripwire)
• intrusion
• cla ssification of people and vehicles
• scene changing
• video tampering
• AcuPick support - technology that uses artificial intelligence on both front-end and back-end to search through massive amounts of video data to quickly locate targets with high precision
• Quick Pick - AI technology enabling, together with the recorder, quick identification of interesting objects (people/vehicles) based on an artificial intelligence algorithm. It allows to extract and compare the colors of clothes and vehicles
• AI SSA AI Smart Scene Adaptive - scene auto-adaptation using deep learning algorithms to detect environmental conditions such as rain, fog, backlight, low light and flickering, in order to set the optimal image parameters
• SMD 4.0 - searching for an object classified as: human, motor vehicle - increased detection distance and resistance to false alarms

Main features:

• Active intrusion deterrence works by blinking blue and red light and siren sound or voice prompts
• WDR - 120 dB - Wide Dynamic Range
• 3D-DNR - Digital Noise Reduction
• F-DNR (Defog) - Reduction of image noise caused by precipitation
• ROI - improve the quality of selected parts of image
• BLC/HLC - Back Light / High Light Compensation
• Full Color - colorful night mode
• White light (LED) illuminator built-in
• Day/Night mode (color/b&w/auto)
• ICR - Movable InfraRed filter
• Auto White Balance
• AGC - Automatic Gain Control
• Image rotation and mirror
• Motion Detection
• Configurable Privacy Zones

Housing: Dome - MetalColor: White"Index of Protection": IP67Power supply:

• PoE (802.3af),
• 12 V DC / 770 mA

Power consumption:

• ≤ 10.1 W @ PoE
• ≤ 8.6 W @ 12 V

Operation temp: -40 °C ... 60 °CWeight: 0.75 kgDimensions: Ø 122  x 111 mm
