Dahua IPC-HFW5631E-ZE
IPC-HFW5631E-ZE 6MP WDR IR Bullet Network Camera > 1/2.9 6Megapixel progressive scan STARVIS CMOS > H. 265&H. 264 dual-stream encoding > 20fps@6M(30722048), 25/30fps@4M(26881520)...
Този продукт вече не се предлага от нито един електронен магазин.
Описание на продукта
IPC-HFW5631E-ZE 6MP WDR IR Bullet Network Camera > 1/2.9 6Megapixel progressive scan STARVIS CMOS > H. 265&H. 264 dual-stream encoding > 20fps@6M(30722048), 25/30fps@4M(26881520)...
Параметри на продукта
Производител
DAHUA
Оформление
Корпусна камера
Захранване
Мрежово и PoE
Резолюция
6 MPx
Минимално фокусно разстояние
2.7 мм
Максимално фокусно разстояние
13.5 мм
Хоризонтален зрителен ъгъл
91 °
Вертикален зрителен ъгъл
58 °
IK защита
IK10
IP защита
IP67
Функция нощно виждане
Да
Тип карта памет
microSD
Параметри на продукта
Производител
DAHUA
Оформление
Корпусна камера
Захранване
Мрежово и PoE
Резолюция
6 MPx
Минимално фокусно разстояние
2.7 мм
Максимално фокусно разстояние
13.5 мм
Хоризонтален зрителен ъгъл
91 °
Вертикален зрителен ъгъл
58 °
IK защита
IK10
IP защита
IP67
Функция нощно виждане
Да
Тип карта памет
microSD
Описание на продукта
IPC-HFW5631E-ZE
6MP WDR IR Bullet Network Camera
> 1/2.9 6Megapixel progressive scan STARVIS CMOS
> H. 265&H. 264 dual-stream encoding
> 20fps@6M(30722048), 25/30fps@4M(26881520)
> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.7mm ~13.5mm motorized lens
> Max. IR LEDs Length 50m
> Micro SD memory, IP67, IK10, PoE
Camera:
Image Sensor- 1/2.9 6Megapixel progressive scan CMOS
Effective Pixels- 3072(H)x2048(V)
RAM/ROM- 512MB/32MB
Scanning System- Progressive
Electronic Shutter Speed- Auto/Manual, 1/3~1/100000s
Minimum Illumination:
- 0.03Lux/F1.4 (Color, 1/3s, 30IRE)
- 0.3Lux/F1.4 (Color, 1/30s, 30IRE)
- 0Lux/F1.4(IR on)
S/N Ratio- More than 50dB
IR Distance- Distance up to 50m (164ft)
IR On/Off Control- Auto/ Manual
IR LEDs- 4
Lens:
Lens Type- Motorized/ Auto Iris(DC)
Mount Type- Board-in
Focal Length- 2.7mm~13.5mm
Max. Aperture- F1.4
Angle of View- H:91~27 , V:58~18
Optical Zoom- 5x
Focus Control- Motorized
Close Focus Distance- 0.3m
DORI Distance:
Lens:
W:
Detect- 79m(259ft)
Observe- 32m(105ft)
Recognize- 16m(52ft)
Identify- 8m(41ft)
T:
Detect- 256m(840ft)
Observe- 102m(334ft)
Recognize- 51m(167ft)
Identify - 25m(84ft)
Pan/Tilt/Rotation:
Pan/Tilt/Rotation Range- Pan:0~360; Tilt:0~90; Rotation:0~360
Intelligence
IVS- Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions- Face Detection
Video
Compression- H. 265+/H. 265/H. 264+/H. 264
Streaming Capability- 3 Streams
Resolution:
6M(30722048)/5M(3072x1728)/ 5M(25921944)/ 4M(26881520)/ 3M(2048x1536)/ 3M(23041296)/ 1080P(19201080)/1.3M(1280x960)/ 720P(1280720)/ D1(704576/704480)/
VGA(640480)/ CIF(352288/352240)
Frame Rate:
- Main Stream: 6M(1~20fps)/4M(1~25/30fps)
- Sub Stream: D1(1~25/30fps)
- Third Stream: 720P(1~25/30fps)
Bit Rate Control- CBR/VBR
Bit Rate- H. 264: 24K ~ 10240Kbps H. 265: 14K ~ 9984Kbps
Day/Night- Auto(ICR) / Color / B/W
BLC Mode- BLC / HLC / WDR
White Balance- Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control- Auto/Manual
Noise Reduction- 3D DNR
Motion Detetion- Off / On (4 Zone, Rectangle)
Region of Interest- Off / On (4 Zone)
Electronic Image Stabilization (EIS)- N/A
Smart IR- Support
Defog- N/A
Digital Zoom- 16x
Flip- 0/90/180/270
Mirror- Off / On
Privacy Masking- Off / On (4 Area, Rectangle)
Audio
Compression- G. 711a/ G. 711Mu/ AAC/ G. 726
Network
Ethernet- RJ-45 (10/100Base-T)
Protocol:
HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;
IGMP; SNMP
Interoperability- ONVIF, PSIA, CGI
Streaming Method- Unicast / Multicast
Max. User Access- 10 Users /20 Users
Edge Storage:
- NAS
- Local PC for instant recording
- Mirco SD card 128GB
Web Viewer- IE, Chrome, Firefox, Safari
Management Software- Smart PSS, DSS, Easy4ip
Smart Phone- IOS, Android
Certifications:
- CE (EN 60950:2000)
- UL:UL60950-1
- FCC: FCC Part 15 Subpart B
Interface
Video Interface- N/A
Audio Interface- 1/1 channel In/Out
RS485- N/A
Alarm:
- 2 channel In: 5mA 5VDC
- 1 channel Out: 300mA 12VDC
Electrical
Power Supply- DC12V, PoE (802.3af)(Class 0)
Power Consumption-
6MP WDR IR Bullet Network Camera
> 1/2.9 6Megapixel progressive scan STARVIS CMOS
> H. 265&H. 264 dual-stream encoding
> 20fps@6M(30722048), 25/30fps@4M(26881520)
> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.7mm ~13.5mm motorized lens
> Max. IR LEDs Length 50m
> Micro SD memory, IP67, IK10, PoE
Camera:
Image Sensor- 1/2.9 6Megapixel progressive scan CMOS
Effective Pixels- 3072(H)x2048(V)
RAM/ROM- 512MB/32MB
Scanning System- Progressive
Electronic Shutter Speed- Auto/Manual, 1/3~1/100000s
Minimum Illumination:
- 0.03Lux/F1.4 (Color, 1/3s, 30IRE)
- 0.3Lux/F1.4 (Color, 1/30s, 30IRE)
- 0Lux/F1.4(IR on)
S/N Ratio- More than 50dB
IR Distance- Distance up to 50m (164ft)
IR On/Off Control- Auto/ Manual
IR LEDs- 4
Lens:
Lens Type- Motorized/ Auto Iris(DC)
Mount Type- Board-in
Focal Length- 2.7mm~13.5mm
Max. Aperture- F1.4
Angle of View- H:91~27 , V:58~18
Optical Zoom- 5x
Focus Control- Motorized
Close Focus Distance- 0.3m
DORI Distance:
Lens:
W:
Detect- 79m(259ft)
Observe- 32m(105ft)
Recognize- 16m(52ft)
Identify- 8m(41ft)
T:
Detect- 256m(840ft)
Observe- 102m(334ft)
Recognize- 51m(167ft)
Identify - 25m(84ft)
Pan/Tilt/Rotation:
Pan/Tilt/Rotation Range- Pan:0~360; Tilt:0~90; Rotation:0~360
Intelligence
IVS- Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions- Face Detection
Video
Compression- H. 265+/H. 265/H. 264+/H. 264
Streaming Capability- 3 Streams
Resolution:
6M(30722048)/5M(3072x1728)/ 5M(25921944)/ 4M(26881520)/ 3M(2048x1536)/ 3M(23041296)/ 1080P(19201080)/1.3M(1280x960)/ 720P(1280720)/ D1(704576/704480)/
VGA(640480)/ CIF(352288/352240)
Frame Rate:
- Main Stream: 6M(1~20fps)/4M(1~25/30fps)
- Sub Stream: D1(1~25/30fps)
- Third Stream: 720P(1~25/30fps)
Bit Rate Control- CBR/VBR
Bit Rate- H. 264: 24K ~ 10240Kbps H. 265: 14K ~ 9984Kbps
Day/Night- Auto(ICR) / Color / B/W
BLC Mode- BLC / HLC / WDR
White Balance- Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control- Auto/Manual
Noise Reduction- 3D DNR
Motion Detetion- Off / On (4 Zone, Rectangle)
Region of Interest- Off / On (4 Zone)
Electronic Image Stabilization (EIS)- N/A
Smart IR- Support
Defog- N/A
Digital Zoom- 16x
Flip- 0/90/180/270
Mirror- Off / On
Privacy Masking- Off / On (4 Area, Rectangle)
Audio
Compression- G. 711a/ G. 711Mu/ AAC/ G. 726
Network
Ethernet- RJ-45 (10/100Base-T)
Protocol:
HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;
IGMP; SNMP
Interoperability- ONVIF, PSIA, CGI
Streaming Method- Unicast / Multicast
Max. User Access- 10 Users /20 Users
Edge Storage:
- NAS
- Local PC for instant recording
- Mirco SD card 128GB
Web Viewer- IE, Chrome, Firefox, Safari
Management Software- Smart PSS, DSS, Easy4ip
Smart Phone- IOS, Android
Certifications:
- CE (EN 60950:2000)
- UL:UL60950-1
- FCC: FCC Part 15 Subpart B
Interface
Video Interface- N/A
Audio Interface- 1/1 channel In/Out
RS485- N/A
Alarm:
- 2 channel In: 5mA 5VDC
- 1 channel Out: 300mA 12VDC
Electrical
Power Supply- DC12V, PoE (802.3af)(Class 0)
Power Consumption-
