Deepcool ASSASSIN VC ELITE WH

DeepCool Assassin VC Elite



EXCEPTIONAL BY DESIGN

Featuring a vapor chamber-enhanced base and seven heat pipes that deliver extremely efficient heat transfer through two fin-array heat sink towers for another level of high heat dissipation. The included DM9 thermal paste meets the rigorous standards used in industrial applications



VAPO R CHAMBER-ENHANCED

Vapor chambers are essentially large, flattened heatpipes with high thermal conductance. In the ASSASSIN IV VC series, the heat is extracted through the coldplate, which starts the cooling process in the planar chamber. The heat gets equalized and sent up the heatpipes to get cooled further by the fin stacks. This solution raises the cooling capacity to an astounding 300W of TDP!



IN QUIET OR PERFORMANCE MODE

With a simple slide of a switch, the ASSASSIN VC ELITE WH can morph from a whisper-quiet cooler when low noise is of the utmost importance to the efficient cooling force DeepCool air coolers are known for.





ALL CLEAR!

The ASSASSIN VC ELITE WH's case is clean, sleek, and helps channel air through the fin towers, while the relocatable 120mm fan provides unobstructed clearance for high-profile RGB RAM.



BE COOL, BE CALM

A key factor in the ASSASSIN VC ELITE WH's extremely silent operation is the use of three-phase, six-slot, four-pole fan motors with low voltage and power consumption. The high-end true FDB bearings in each of the fans are the gold standard, and for good reason. DeepCool is so confident in our new design that the ASSASSIN VC ELITE WH comes with 6 years of limited warranty coverage!

THE FLOW BELOW

Due to the center 140mm fan sitting deep into the heart of the ASSASSIN VC ELITE WH, there is a lower flow of air that provides additional cooling to the toasty surrounding VRMs.



STREAMLINED INSTALLATION

Installing larger air coolers can be difficult and is a prime reason the hardware and installation was designed to be extremely user friendly. Even the magnetic top fan cover was crafted with ease of installation in mind.



Application For

Intel

LGA2066/2 011-v3/2011/1851/1700/1200/1150/1151/115 5

AMD

AM5/AM4



Pr oduct Dimensions 144×147×164 mm(L×W×H)Heatsink Dimensions 140×110×160 mm(L×W×H)Net Weight 1772 gHeatpipe Ø6 mm×7 pcsFan Dimensions 140×140×25 mm(L×W×H) / 120×120×25 mm(L×W×H)Fan Speed (Performance Mode) 500~1800 RPM±10% / 500~1700 RPM±10%Fan Airflow (Performance Mode) 61.25 CFM / 58.06 CFMFan Air Pressure (Performance Mode) 3.76 mmAq / 2.1 mmAqOverall Noise (Performance Mode) ≤29.3 dB(A)Fan Speed (Quiet Mode) 500~1450 RPM±10% / 500~1350 RPM±10%Fan Airflow (Quiet Mode) 48.55 CFM / 46.75 CFMFan Air Pressure (Quiet Mode) 2.46 mmAq / 1.35 mmAqOverall Noise (Quiet Mode) ≤22.6 dB(A)Fan Connector 4-pin PWMBearing Type Fluid Dynamic BearingMotor Type 6-Pole Fan MotorFan Rated Voltage 12 VDCFan Rated Current 0.2 A / 0.2 AFan Power Consumption 2.4W / 2.4 WRated Voltage 12 VDCPower Consumption(Performance Mode) 4.8 WPower Consumption(Quiet Mode) 3.6 W
