Deepcool R-ASN4S-BGGPMN-G

DeepCool Assassin 4S



Beauty in simplicity

The elegant design of the ASSASSIN 4S is not just visually pleasing; it also leads to optimal air flow and maximum compatibility.



Quiet or performance mode

With a simple slide of a switch, the ASSASSIN 4S can morph from a whisper-quiet cooler when low noise is of the utmost importance to the efficient cooling force DeepCool air coolers are known for.

Let it shine!

The shell of ASSASSIN 4S is clean, sleek, and helps channel air through the fin towers, while the slimmer profile provides unobstructed clearance for high-profile RGB RAM.

Be cool, be calm

A key factor in the ASSASSIN 4S's extremely silent operation is the use of three-phase, six-slot, four pole fan motors with low voltage and power consumption. DeepCool is so confident in our new design that the ASSASSIN 4S comes with 6 years of limited warranty coverage!

Application For



Intel

LGA2066/2011-v3/2011/1851/1700/1200/1151 /1150/1155



AMD

AM5/ AM4



Specifications

Product Dimensions 116×147×164 mm(L×W×H)Heatsink Dimensions 140×110×160 mm(L×W×H)Net Weight 1380 gHeatpipe Ø6 mm×7 pcsFan Dimensions 140×140×25 mm(L×W×H)Fan Speed (Performance Mode) 500~1800 RPM±10%Fan Airflow (Performance Mode) 61.25 CFMFan Air Pressure (Performance Mode) 3.76 mmAqOverall Noise (Performance Mode) ≤29.3 dB(A)Fan Speed (Quiet Mode) 500~1450 RPM±10%Fan Airflow (Quiet Mode) 48.55 CFMFan Air Pressure (Quiet Mode) 2.46 mmAqOverall Noise (Quiet Mode) ≤22.6 dB(A)Fan Connector 4-pin PWMBearing Type Fluid Dynamic BearingFan Rated Voltage 12 VDCFan Rated Current 0.2 AFan Power Consumption 2.4 WRated Voltage 12 VDCPower Consumption(Performance Mode) 3.6 WPower Consumption(Quiet Mode) 2.4 W
