EIZO ColorEdge CS2400S-LE





Technical data



GENERAL Item no. CS2400S-LECase colour BlackSolution area Photography, Video & GraphicsProduct line ColorEdgeAreas of application Photography, image editing and retouching, Design, creation and illustrationEAN 4995047065098DISPLAY Screen size [in inches] 24,1Screen size [in cm] 61,1Format 16:10Viewable image size (width x height) 518,4 x 324Ideal and recommended resolution 1920 x 1200Pixel pitch [mm] 0,27 x 0,27Resolution supported 1920 x 1200 (@ 60 Hz, with Apple M1/M2 @ 30 Hz), 1920 x 1080 (Full HD), 1200p (@ 60 Hz), 1200p (@ 50 Hz), 1080p (@ 60 Hz), 1080i (@ 60 Hz), 1080p (@ 50 Hz), 1080i (@ 50 Hz), 1080p (@ 30/25/24 Hz), 720p (@ 60 Hz), 720p (@ 50 Hz), 576p (@ 50 Hz), 576i (@ 50 Hz), 480p (@ 60 Hz), 480i (@ 60 Hz)Panel technology IPS (Wide Gamut)Max. viewing angle horizontal 178Max. viewing angle vertical 178Number of colours or greyscale 1.07 billion colors (USB-C, 10-bit), 1.07 billion colors (HDMI, 10 Bit), 1.07 billion colors (DisplayPort, 10 Bit), 16.7 million colors (DisplayPort, 8 Bit), 16.7 million colors (HDMI, 8 Bit), 16.7 million colors (USB-C, 8 Bit)Colour palette/look-up table 278 trillion color tones / 16 BitMax. colour space (typical) DCI P3 (>95%), AdobeRGB (>99%), ISO Coated V2 (>99%), sRGB (100%)Max. brightness (typical) [in cd/m2] 410Recommended brightness [in cd/m2] 120Max. dark room contrast (typical) 1350:1Response time grey-grey alternation (typical) [in ms] 19Max. refresh rate [in hertz] 60Backlight LEDFEATURES & OPERATIONUSB-C docking  KVM switch  Hardware calibration ColorEdge  Preset colour/greyscale modes 1x manual memory location, AdobeRGB, sRGB, additional memory spaces through calibrationDigital Uniformity Equalizer (homogeneity correction)  No flickering thanks to hybrid controls  I/P conversion  Signal range extension (HDMI)  HDCP Decoder  Gamut Clipping  Input signal identification  OSD language de, en, frOSD setting options Signal information, Color Mode, Brightness, Contrast, Color temperature/White point, Gamma, Colour tone, Color saturation, 6 Colors, Scaling, Color matrix YUV/ RGB, Input Range, Menu Rotation, Skip signal input, Custom key, OSD language, Signal input, DUE priorityButton Guide  Integrated power unit  CONNECTIONSVi deo Input HDMI (Deep Color, HDCP 2.3), USB-C (DisplayPort Alt Mode, HDCP 2.3), DisplayPort (HDCP 2.3)USB specification USB 5Gbps (USB 3)USB upstream ports 1 x type C (DisplayPort Alt Mode, 70 W max. ), 1 x type BUSB downstream ports 4 x Typ A ( 2 x 5Gbps (USB 3), 2 x USB 2)Video signal DisplayPort, HDMI (RGB, YUV)ELECTRICAL DATAFrequency USB-C, DisplayPort: 26-76 kHz/23-61 Hz; HDMI: 15-76
kHz/23-61 HzPower consumption (typical) [in watt] 18Maximum Power Consumption [in watt] 149 (at maximum brightness with all signal inputs and USB ports in use)Power Save Mode [in watt] 0.3Power consumption off [in watt] 0Energy efficiency class EEnergy consumption/1000h [in kWh] 16Power supply AC 100-240V, 50/60HzPower supply via USB C 70Power management  DIMENSIONS & WEIGHTDimensions [mm] 554 x 396-551 x 245Weight [in kilograms] 8.2Swivel 344dimensionTilt 5 / 35Housing dimension details 90° (clockwise)Height adjustment range [mm] 155Hole spacing 100 x 100CERTIFICATION AND STANDARDSCertification< /strong> CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, RoHS, WEEE, China RoHS, CCCSOFTWARE & ACCESSORIESSoftwareQuic k Color Match, ColorNavigator Network, ColorNavigatorAdditional supply Calibration report, Signal cable HDMI - HDMI, USB/signal cable (USB-C - USB-C), Power cord, Quick guideAccessories PM200-K, CP200, EX4, CH2400
