Intel Xeon 4-Core E5-1620 3.6GHz LGA2011 Tray (CM8062101038606)

Intel® Xeon® Processor E5-1620 (10M Cache, 3.60 GHz, 0.0 GT/s Intel® QPI)

Processor Number - E5-1620
# of Cores - 4
# of Threads - 8
Clock Speed - 3.6 GHz
Max Turbo Frequency - 3.8 GHz
Instruction Set - 64-bit
Instruction Set Extensions - AVX
Embedded Options Available - No
Lithography - 32 nm
Max TDP - 130 W
VID Voltage Range - 0.60V - 1.35V

Memory Specifications

Max Memory Size (dependent on memory type) - 375 GB
Memory Types - DDR3-800/1066/1333/1600
# of Memory Channels - 4
Max Memory Bandwidth - 51.2 GB/s
ECC Memory Supported - Yes

Expansion Options

PCI Express Revision - 3.0
# of PCI Express Lanes - 40

Package Specifications

Max CPU Configuration - 1
TCASE - 64.0 °C
Package Size - 52.5mm x 45.0 mm
Sockets Supported - FCLGA2011
Low Halogen Options Available - See MDDS

Advanced Technologies

Intel® Turbo Boost Technology - 2.0
Intel® vPro Technology - Yes
Intel® Hyper-Threading Technology - Yes
Intel® Virtualization Technology (VT-x) - Yes
Intel® Virtualization Technology for Directed I/O (VT-d) - Yes
Intel® VT-x with Extended Page Tables (EPT) - Yes
Intel® Trusted Execution Technology - Yes
AES New Instructions - Yes
Intel® 64 - Yes
Idle States - Yes
Enhanced Intel SpeedStep® Technology - Yes
Intel® Demand Based Switching - Yes
Thermal Monitoring Technologies - Yes
Intel® Flex Memory Access - Yes
Execute Disable Bit - Yes
Intel® Identity Protection Technology - Yes
