Mercusys MB230-4G

Mercusys MB230-4G

4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router

• 4G+ network – Enjoy the 4G+ Cat 6 download speeds up to 300 Mbps.
• Plug a SIM card and play – No configurations needed, compatibility of SIM cards are assured by years of field tests.
• Dual Band 1200 Mbps WiFi – Fast WiFi speeds up to 300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band.
• Simultaneous Connection – Enjoy and share internet access with up to 64 Wi-Fi devices.
• 4G/3G ExternalAntenna Ports –  Enable connect external antennas for wider coverage.
• Wi-Fi router mode – Plug an Ethernet cable into the LAN/WAN port for flexible access if you can't get a 4G connection.
• EasyMesh Compatible – Works with EasyMesh routers and range extenders to form seamless whole home Mesh WiFi, preventing drops and lag when moving between signals.



WiFi Wherever You Need It

Enjoy unmatched convenience and versatility with fast, stable WiFi whether you’re at home or working remotely.





Extra Fast 4G+ Cat6 Speed for Reliable WiFi

Working as a 4G+ WiFi router, MB230-4G uses 4G+ Cat6 technology to achieve superfast speeds up to 300 Mbps download and 50 Mbps upload. It can also share dual band WiFi network speeds up to 1.2 Gbps. The 2.4 GHz band is perfect for music streaming and online shopping, while the 5 GHz band, with speeds of 867 Mbps, handles bandwidth-intensive HD streaming and gaming.





Share WiFi with Your Friends

A remarkable number of wireless devices are compatible with this 4G+ router without any issues. Up to 64 simultaneous connections for tablets, laptops, mobile phones, and other devices.





CategorySpecificationWi reless  Network Type EU:FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)TDD-LTE: B38/B40 (2600/2300 MHz)HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)Wi-Fi Class AC1200Wi-Fi (2.4 GHz) 300 MbpsWi-Fi (5 GHz) 867 MbpsWireless Standards IEEE 802.11ac/a/b/g/nFrequency 5 GHz, 2.4 GHzReception Sensitivity 11g 6Mbps: -95dBm11g 54Mbps: -77dBm11n HT20 MCS7: -74dBm11n HT40 MCS7: -71dBm11a 6Mbps: -92dBm11a 54Mbps: -75dBm11ac VHT20 MCS8: -70dBm11ac VHT40 MCS9: -65dBm11ac VHT80 MCS9: -61dBmTransmission Power 2.4 GHz < 20dBm (EIRP)5 GHz < 23dBm (EIRP)Wireless Security WPA-PSK / WPA2-PSK / WPA3-SAEWireless Functions Smart ConnectWPSWireless ScheduleHardware  Dimensions 95 × 61.05 × 165.97 mm (3.74 × 2.40 × 6.53 in)Interfaces 1× Gigabit LAN/WAN Port 1× Gigabit LAN Port 2× 4G/3G External Antenna Ports 1× Nano SIM Card SlotAntenna InternalButton WPS/Reset ButtonExternal Power Supply 12V/1ALED Indicators 1× Power 1× LAN 3× SignalLTE Standard Cat 6300/50 Mbps DL/ULSoftware  Operation Mode 3G/4G RouterWireless RouterCellular Mode 4G Mode3G ModeCellular APN Data RoamingBand SearchNetwork SearchProfile CreateAPN SettingsISP File UpgradePIN ManagementWAN Mode Dynamic IPStatic IPPPPoEPPTPL2TPNAT Forwarding ALGVirtual ServerPort TriggeringUPnPDMZProtocols IPv4, IPv6Data Settings Data StatisticsData LimitParental Controls Time ControlWebsite FilteringGuest Network 2.4 GHz Guest Network5 GHz Guest NetworkDHCP ServerDHCP Client ListAddress ReservationDDNS MERCUSYS DDNSDynDnsNO-IPSMS InboxNew MessageOutboxDraftsQoS √Security IPv4 SPI FirewallAccess ControlIP & MAC BindingIPv6 FirewallSystem Settings Time & LanguageLED ControlDiagnosticsFirmware UpgradeBackup & RestoreRebootAdministrationSystem LogCWMP SettingsDevice Management MERCUSYS APPWeb GUISystem Language English Deutsch Español Français Italiano Polski РусскийTR-069 √
