Mercusys MR85X AX3000

Mercusys MR85X



AX3000 Dual-Band Wi-Fi 6 Router

OPTIMAL WIFI 6 SPEEDS – Optimal WiFi 6 speeds reaching up to 3 Gbps for faster browsing,  streamings, and downloading, all at the same time.

2.5 Gbps MULTI-GIG PORT – Break through the 1G bottleneck and drive your devices to peak performance.

MORE DEVICES, MORE FUN – Supports MU-MIMO and OFDMA to reduce congestion and quadruple the average throughput.

WiFi THAT GOES FARTHER – 4× multi-directional antennas with Beamforming boost stable connections throughout your home for strong WiFi signals in every corner

OVERALL SECURITY PROTECTION – The latest WPA3 provides improved WiFi security

G IGABIT WIRED CONNECTIONS – Make full use of your internet access and transfer data at dizzying speeds for peak performance

ECO-FRIENDLY POWER SAVING – Target Wake Time (TWT) reduces power consumption for your mobile and IoT devices during data transmissions

LESS WIFI INTERFERENCE – Minimizes the interference from neighboring signals to improve transmission efficiency with BSS coloring

SMART CONNECT – Intelligently chooses the best available band for each device





Here’s a fully merged, standard-format table containing all the specs you provided, organized neatly for easy reference:

Specification DetailsWi-Fi Class AX3000Wi-Fi (2.4 GHz) 574 MbpsWi-Fi (5 GHz) 2402 MbpsWireless Standards 802.11ax/ac/a/b/g/nMax Channel Width 160 MHzReception Sensitivity (5 GHz) 11a 6Mbps: -95 dBm11a 54Mbps: -76.5 dBm11n HT20 MCS7: -76 dBm11n HT40 MCS7: -73 dBm11ac VHT20 MCS8: -71.5 dBm11ac VHT40 MCS9: -67 dBm11ac VHT80 MCS9: -63.5 dBm11ax HE20 MCS11: -64.5 dBm11ax HE40 MCS11: -63 dBm11ax HE80 MCS11: -58.5 dBm11ax HE160 MCS11: -56 dBmReception Sensitivity (2.4 GHz) 11g 6Mbps: -97 dBm11g 54Mbps: -79 dBm11n HT20 MCS7: -78 dBm11n HT40 MCS7: -75 dBm11ax HE20 MCS11: -66.5 dBm11ax HE40 MCS11: -65.5 dBmMax Wi-Fi Modulation 1024 QAMWireless Security WPA/WPA2/WPA3Wireless Functions Guest Network, Smart Connect, Wireless Schedule, WPS, AP Isolation, Airtime FairnessDimensions 209 × 171.7 × 42.4 mm (8.2 × 6.8 × 1.7 in)Interfaces 1× 2.5G WAN, 3× GE LANAntenna 2× 5G External Antennas (5dBi)1× 2.4G & 5G External Antenna (2.4G: 3dBi, 5G: 5dBi)1× 2.4G External Antenna (5dBi)Button 1× WPS Button, 1× Reset ButtonInstallation Desktop, Wall-mountLED 1× SYSRetail Package Dimension 359 × 274 × 60 mmUnits per Carton 10Carton Dimension 560 × 370 × 310 mmIPTV IGMP Proxy, IGMP Snooping, Bridge, Tag VLANPower Input: 100~240V, 50/60HzOutput: 12V/1.5AOperation Mode Router/AP modeWAN Mode Dynamic IP, Static IP, PPPoE, PPTP, L2TPNAT Forwarding Port Forwarding, Port Triggering, DMZ, UPnPProtocols IPv4, IPv6Guest Network 2.4G Guest Network, 5G Guest NetworkParental Controls Profile Settings, Time Control, Pause the Internet, Website FilteringDHCP Address Reservation, DHCP Client List, ServerDDNS MERCUSYS, NO-IP, DynDNSVPN Server OpenVPN, PPTP, L2TP/IPSec, WireGuardVPN Client OpenVPN, PPTP, L2TP/IPSec, WireGuardEasymesh Easymesh CompatibleQoS Time Settings, Priority ControlSecurity SPI Firewall, Access Control, IP & MAC BindingKill Switch SupportISP Feature CWMP, ISP Preset (Agile Config), SuperadminSystem Firmware Upgrade, Backup and Restore, Administration, System Log, Time & Language Settings, RebootDiagnostics Ping, TracerouteLED Management LED Control, Night ModeDevice Management MERCUSYS APP, WebpageCloud MERCUSYS IDLanguage Bulgarian, Czech, Danish, German, English, Spanish, Finnish, French, Hungarian, Italian, Japanese, Korean, Dutch, Norwegian, Polish, Portuguese, Portuguese - Brazil, Romanian, Russian, Slovak, Swedish, Turkish, Ukrainian, Vietnamese, Chinese - TaiwanAdvanced Features OFDMA, MU-MIMO, BSS Color, BeamformingWeb Server Manage and configure device through web (HTTP/HTTPS), Port: 80/443, Protocol: TCPDHCP Server IP address assignment (DHCP), Port: 67, Protocol: UDPDNS DNS, Port: 53, Protocol: TCP & UDPApp Management Manage and configure device through app, Port: 20001 TCP, Port: 20002 UDP
