PLANET ISW-801T

Planet ISW-801T

Slim Type with more Practicability and Convenience
PLANET ISW-801T, an Industrial 8-port Fast Ethernet Switch, provides non-blocking wire-speed performance in harsh industrial environment. It also provides 8-port 10/100BASE-TX RJ45 copper interfaces delivered in an IP30 rugged, strong case with redundant power system. Its slim case is suitable for such applications as surveillance system deployments, control management and wireless service in climatically demanding environments with wide temperature range from -40 to 75 degrees C.

Hardware Specifications
10/100BASE-TX Auto MDI/MDIX Ports 8
LED Indicators 3 x LED for System and Power
■ Green: DC Power 1
■ Green: DC Power 2
■ Green: Power Fault

1x LED for each Copper Port
■ Green: 10/100 LNK/ACT
Enclosure IP30-rated metal case

Dimensions (W x D x H) 135 x 87 x 32 mm
Weight 428g
ESD Protection 6KV DC
EFT Protection 6KV DC
Power Requirements 12~48V DC, redundant power with polarity reverse protection function, 24V AC power support
Power Consumption/Dissipation 2.1 watts/7.1BTU
Installation DIN rail kit and wall-mount ear
Alarm Provides one relay output for power failure
Alarm relay current carry ability: 3A @ DC 30V
Connector Removable 6-pin terminal block
Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2

Switch Specifications
Switch Processing Scheme Store-and-Forward
Address Table 1K
Buffer Memory Embedded 448K bits packet buffer
Flow Control Back pressure for half duplex,
IEEE 802.3x pause frame for full duplex
Switch Fabric 1.6Gbps
Throughput (packet per second) 1.19Mpps
Network Cables 10BASE-T: 2-pair UTP Cat. 3, 4, 5, up to 100 meters
100BASE-TX: 2-pair UTP Cat. 5, 5e up to 100 meters

Standards Conformance
Standards Compliance IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full Duplex Flow Control
IEEE 802.3az Energy Efficient Ethernet
Temperature Operating: -40~75 degrees C
Storage: -40~75 degrees C
Humidity Operating: 5% to 95%, Storage: 5% to 95% (non-condensing)
Regulatory Compliance FCC Part 15 Class A, CE
Stability Testing IEC60068-2-32 (free fall)
IEC60068-2-27 (shock-proof)
IEC60068-2-6 (vibration-proof)
