Samsung CY-KM24AP

Samsung LH24KMATBGCXEN

Designed for every business, delivering peace of mind

Samsung's latest technology delivers a new standard of kiosk, offering a compact, space-saving design, advanced security provided by Knox and easy management and maintenance for reliable performance. Built based on Samsung's SoC(System on Chip) technology, it is the ideal solution for any business.

Modular functionality to support any payment type

The Samsung Kiosk adopts a modular design that provides a variety of payment options including credit card, barcode, QR code and NFC, along with a built-in printer. This means it needs no additional peripherals for an advanced, all-in-one solution that also makes maintenance fast and easy.

Specifications:

• Display




  • Diagonal Size 23.8"


  • Panel Type ADS


  • Resolution 1,920 x 1,080


  • Pixel Pitch (HxV) 0.2745 x 0.2745 mm







  • Brightness (Typical) 250cd(Typ, w/o glass)


  • Contrast Ratio 1000:1(without glass)


  • Viewing Angle (Horizontal/Vertical) 178/178


  • Response Time 14ms







  • Colour Gamut 72%


  • Glass Haze 25 (w/o glass)


  • H-Scanning Frequency 48~75KHz


  • Maximum Pixel Frequency 594MHz







  • V-Scanning Frequency 56~84.5Hz


  • Dynamic Contrast Ratio Mega


  • Operation Time Support 16/7






• Connectivity



  • HDMI In 1







  • USB 1


  • RS232 In Yes







  • RJ45 In Yes


  • WiFi Yes





• Power




  • Power Supply AC100-240V 50/60Hz


  • Power Consumption (Off Mode) N/A


  • Power Consumption (On Mode) 49.5


  • Power Consumption (Sleep Mode) 0.5 W






• Dimension



  • Set Dimension (WxHxD) 547.9 x 334.4 x 48.8 mm


  • Package Dimension (WxHxD) 620 x 419 x 122 mm






• Weight



  • Set Weight with Stand 4.4 kg


  • Package Weight 5.4 kg






• Operation Conditions



  • Temperature 0℃~40℃


  • Humidity 10 ~ 80%, non-condensing






• Mechanical Specification



  • Bezel Width UD: 17.9 / LR: 9.4


  • Frame Material Non-Glossy






• Optional Feature



  • Touch Yes


  • Stand Yes
