Sudokoo R-SK620V-WHNDAN-GAS

Sudokoo SK620V



Engineered for performance
Achieve peak performance on your CPU with the AM5 focused Sudokoo SK620V WHITE, designed to deliver substantial cooling capacity for heavily overclocked systems. Equipped with six heat pipes for efficient thermal transfer from the cold plate to the fin stacks, ensuring another level of high heat dissipation.



Digital precision

Stay on top of your system's performance with the enhanced quad-segmented display, giving you real-time monitoring of CPU temperature, usage, wattage, and frequency. The digital panel is powered by a pogo pin and pad contact point. The display is controlled via ¹MasterCraft and only requires an open USB 2.0 header.



Keep your cool

Quiet performance is a hallmark of the SK620V WHITE, thanks to its efficient 3-phase, 4-pole, 6-slot FOC closed-loop control fan motor that minimizes both voltage and power consumption.

2000±10% RPM(max)

Fan Speed

56.46 CFM

Fan Airflow

2.93 mmAq

Fan Air Pressure

≤29.9 dB(A)

Fan Noise



El ite heat flow design

Thanks to the enclosed dual-tower heatsink design, the SK620V WHITE's case helps channel air through the fin towers, which fuses ultimate cooling performance with superb quietness of operation.



Secure glide fan mount design

The advanced fan mount system offers adjustable height (three height levels), ensuring compatibility with nearly any RAM module in the market while enhancing visibility for RGB lighting.



Specifications



Product Dimensions 145×144×164 mm(L×W×H)Heatsink Dimensions 125×115×153 mm(L×W×H)Net Weight 1645 gHeatpipe Ø6 mm×6 pcsFan Dimensions 120×120×25 mm(L×W×H)Fan Speed 2000±10% RPM(max)Fan Airflow 56.46 CFMFan Air Pressure 2.93 mmAqFan Noise ≤29.9 dB(A)Fan Connector 4-pin PWMBearing Type Fluid Dynamic BearingFan Rated Voltage 12 VDCFan Rated Current 0.22 AFan Power Consumption 2.64 WDisplay Module Rated Current 0.09 A±10%Display Module Rated Voltage 5 VDCDisplay Module Power Consumption 0.45 WDisplay Area 70.7x27.8 mm
