Synology FlashStation FS3410

Synology SA3410

Flexibly expand storage capacity

Scale up your SA3610 and SA3410 flexibly to meet growing data demands whenever needed. Increase your storage capacity by adding up to seven 12-bay RX1222sas expansion units as your deployment grows.



Specifications:

Hardware Specifications

SA3410

CPU
CPU Model
Intel Xeon D-1541

CPU Quantity
1

CPU Architecture
64-bit

CPU Frequency
8-core 2.1 (base) / 2.7 (turbo) GHz

Hardware Encryption Engine (AES-NI)
Yes

Memory
System Memory
16 GB DDR4 ECC RDIMM

Memory Module Pre-installed
16 GB (16 GB x 1)

Total Memory Slots
4

Maximum Memory Capacity
128 GB (32 GB x 4)

Storage
Drive Bays
12

Maximum Drive Bays with Expansion Unit
96 (RX1222sas x 7)

Compatible Drive Type*

• 3.5" SAS HDD


• 2.5" SAS SSD


• 3.5" SATA HDD


• 2.5" SATA SSD

Hot Swappable Drive*
Yes

External Ports
RJ-45 1GbE LAN Port
4 (with Link Aggregation / Failover support)

RJ-45 10GbE LAN Port
2 (with Link Aggregation / Failover support)

Management LAN Port
1

Max. number of LAN ports
15

USB 3.2 Gen 1 Port*
2

Expansion Port
1

Notes

• This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.


• The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

PCIe
PCIe Expansion
2 x Gen3 x8 slots (x8 link)

File System
Internal Drives

• Btrfs


• EXT4

External Drives

• Btrfs


• EXT4


• EXT3


• FAT


• NTFS


• HFS+


• exFAT

Appearance
Form Factor (RU)
2U

Size (Height x Width x Depth)
88 mm x 482 mm x 724 mm

Weight
14.5 kg

Others
System Fan
80 mm x 80 mm x 4 pcs

Fan Speed Mode

• Full-Speed Mode


• Cool Mode


• Quiet Mode

Easy Replacement System Fan
Yes

Power Recovery
Yes

Noise Level*
49.8 dB(A)

Scheduled Power On / Off
Yes

Wake on LAN / WAN
Yes

Power Supply Unit / Adapter
550 W

Redundant Power Supply
Yes

AC Input Power Voltage
100V to 240V AC

Power Frequency
50/60 Hz, Single Phase

Power Consumption
136.15 W (Access)

58.48 W (HDD Hibernation)

British Thermal Unit
464.56 BTU/hr (Access)

199.54 BTU/hr (HDD Hibernation)

Temperature
Operating Temperature
0°C to 35°C (32°F to 95°F)

Storage Temperature
-20°C to 60°C (-5°F to 140°F)

Relative Humidity
5% to 95% RH

Certification


• FCC


• CE


• BSMI


• VCCI


• RCM


• UKCA


• EAC


• CCC


• KC


• UL
