Synology RS422+

Synology RS422+



Streamline your data management

With its compact 1U form factor and powerful Synology DiskStation Manager (DSM) operating system, the 4-bay Synology RackStation RS422+ is an affordable all-in-one solution for small businesses and homelab owners looking to meet their daily data management, sharing, synchronization, and backup needs.

Space-saving design for flexible deployment

Thanks to its compact 1U chassis, the RS422+ fits perfectly in a 2-post or wall mount rack. Deploy it in space-limited environments or anywhere else without investing in costly railkits or other server equipment.



Specifications:< /strong>

CPU CPU Model AMD Ryzen R1600  CPU Quantity 1  CPU Architecture 64-bit  CPU Frequency 2-core 2.6 (base) / 3.1 (turbo) GHz  Hardware Encryption Engine (AES-NI) YesMemory System Memory 2 GB DDR4 ECCStorage Drive Bays 4  Compatible Drive Type*

• 3.5" SATA HDD
• 2.5" SATA SSD

  Hot Swappable Drive* YesExternal Ports RJ-45 1GbE LAN Port* 2 (with Link Aggregation / Failover support)  USB 3.2 Gen 1 Port* 1  Notes

• This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
• The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

PCIe PCIe Expansion 1 x Gen3 x2 network upgrade slotFile System Internal Drives

• Btrfs
• EXT4

  External Drives

• Btrfs
• EXT4
• EXT3< /li>
• FAT
• NTFS
• HFS+
• exFAT

Appearance Form Factor (RU) 1U  Size (Height x Width x Depth) 44 mm x 478 mm x 327.5 mm  Weight 4.38 kgOthers System Fan 40 mm x 40 mm x 3 pcs  Fan Speed Mode

• Full-Speed Mode
• Cool Mode
• Quiet Mode

  Power Recovery Yes  Noise Level* 28.5 dB(A)  Scheduled Power On / Off Yes  Wake on LAN / WAN Yes  Power Supply Unit / Adapter 100 W  AC Input Power Voltage 100V to 240V AC  Power Frequency 50/60 Hz, Single Phase  Power Consumption 37.93 W (Access)
13.43 W (HDD Hibernation)  British Thermal Unit 129.42 BTU/hr (Access)
45.83 BTU/hr (HDD Hibernation)Temperature Operating Temperature 0°C to 35°C (32°F to 95°F)  Storage Temperature -20°C to 60°C (-5°F to 140°F)  Relative Humidity 5% to 95% RHCertification

• FCC
• CE
• BSMI
• VCCI
• RCM
• UKCA
EAC
• CCC
• KC

< strong>Compatible drives:
