Teltonika RUT241

TELTONIKA NETWORKS RUT241 4G/LTE/3G/2G WiFi routerTELTONIKA NETWORKS RUT241 4G/LTE/3G/2G WiFi router:Manufacturer : TELTONIKA NETWORKSManufacturer Part No : RUT241000000Marketing DescriptionEquipped with 4G LTE, Wi-Fi, and two Ethernet ports, RUT241 offers unstoppable connection continuity with automatic WAN failover. Industrial design, compact size, multiple connection interfaces, and compatibility with RMS make this device an excellent fit in numerous IoT and M2M solutions. Product Features

• 4G LTE (Cat 4), 3G, 2G
• Wireless access point with hotspot functionality
• Automatic switching to available backup connection
• For remote management, access and VPN services

GeneralDevice Type : Wireless routerEnclosure Type : Desktop, DIN rail mountableConnectivity Technology : Wired, wirelessData Link Protocol : IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Ethernet, Fast EthernetFrequency Band : 2.4 GHzCapacity : Simultaneous connections: 50
IPSec VPN tunnels: 4Network / Transport Protocol : TCP/IP, UDP/IP, IPv4, IPv6, NTP, DNS, HTTP, HTTPs, FTP, SMTP, ARP, PPPoE, DHCP, Telnet, DDNS, OpenVPN, L2TP, PPTP, WireGuardRouting Protocol : BGP, OSPFv2, RIP-2, RIP-1, RIPng, OSPF for IPv6, VRRPRemote Management Protocol : ICMP, SSH, SNMP, MQTT, TR-069, SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS, JSON, ModbusEncryption Algorithm : WPA2-Enterprise, PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK, AES-CCMP, TKIP, SSL 3.0, TLS, DES, RC2, Blowfish, CAST5, 128-bit AES, 256-bit AES, 192-bit AES, IKEv1, IKEv2, 3DES, MODBUSAuthentication Method : RADIUS, X. 509 certificatesFeatures : SMS alert, white list, black list, band management, auto APN, bridge mode, software access point, client separation, Auto Cipher modes, Stealth Mode, MACsec, Captive Portal, auto-uplink (auto MDI/MDI-X), PPP, Telnet client, WOL, VoIP passthrough support, connection monitoring, DHCP relay, QoS, load balancing, PSK, digital certificates, DDoS Protection, VLAN support, mobile quota control, MAC address filtering, GRE tunneling, FOTA, Teltonika RMS, reset key, aluminium housing, WAN failoverCompliant Standards : IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, UPnP, IP30, RED, UKCA, EN 301 489-1 V2.2. 3, EN 301 489-17 V3.2. 4 (2020-09), EN 301 489-52 V1.2. 0, EN 55032:2015+A1:2020, EN 55035:2017+A11:2020, EN 61000-3-3:2013+A1:2019, EN IEC 61000-3-2:2019, EN 61000-4-2:2009, EN 61000-4-3:2020, EN 61000-4-4:2012, EN 61000-4-5:2014+A1:2017, EN 61000-4-6:2014, EN IEC 61000-4-11:2020, EN 300 328 V2.2. 2, EN 301 511 V12.5. 1, EN 301 908-1 V13.1. 1, EN 301 908-2 V13.1. 1, EN 301 908-13 V13.1. 1, EN IEC 62311:2020, EN 50665:2017, EN IEC 62368-1:2020+A11:2020, IEC 62368-1:2018Processor : 1 x MediaTek MIPS 24KC 580 MHzRAM : 128 MBFlash Memory : 16 MBStatus Indicators : Power, status, signal strengthCommunicationsType : Wireless cellular modemMobile Communication Protocol : FDD LTEGeneration : 2G, 3G, 4GCellular Band : LTE B1, LTE B20, LTE B28A, LTE B3, LTE B7, LTE B8Max Transfer Rate : 150 MbpsIP TelephonyVoIP Protocols : SIP, H. 323Internet of Things (IoT)Internet of Things (IoT) Compatible : YesPlatform : Clouds of Things, ThingWorx, Cumulocity, AzureExpansion / ConnectivityInterfaces : LAN: 1 x 10Base-T/100Base-TX - RJ-45
WAN: 1 x 10Base-T/100Base-TX - RJ-45
Antenna: 2 x SMA
Antenna: 1 x RP-SMA
1 x DI
1 x DOExpansion Slots : 1 (total) / 1 (free) x Mini-SIMAerialAerial : External detachableAntenna Qty : 3PowerPower Device : External power adapterVoltage Required : DC 9 - 30 VElectric Current Required : 1 APower Consumption Operational : 6.5 WattMiscellaneousIncluded Accessories : SIM card adapter kit, WiFi aerial, 2 x LTE aerialsCables Included : 1 x network cable - 1.5 mLocalisation : EuropeSoftware / System RequirementsOS Provided : RutOSSoftware Included : ZeroTier VPNDimensions & WeightWidth : 8.3 cmDepth : 7.4 cmHeight : 2.5 cmWeight : 125 gDimensions & Weight (Shipping)Shipping Width : 17.3 cmShipping Depth : 14.8 cmShipping Height : 7.1 cmEnvironmental ParametersMin Operating Temperature : -40 °CMax Operating Temperature : 75 °CHumidity Range Operating : 10 - 90% (non-condensing)Technical data provided by third party. We assume no liability for errors within these data.
