Tenda G3

Tenda G3

Tenda G3 equips with high performance CPU with maximum frequency up to 800MHz and 4 WAN ports which provides multiple functions of load balance, traffic control and user authentication. With ac and multiple modes of router mode and bridge mode, G3 can manage 8 access points and provide capacity for 120 concurrent network devices. Through convenient network deployment and convenient setting, G3 provides the best wireless coverage solutions for small businesses, restaurants , cafes and so on.

>> Multi-WAN Ports.
>> Portal Authentication.
>> AP Management.
>> QoS Bandwidth Management .
>> PPTP/L2TP/IPSec VPN.





Multi-WAN Ports

Equipped with 3 bandwidth balancing modes based on session, IP and intelligent load balancing, and supports average bandwidth allocation and bandwidth expansion of 4 ports.





Portal Authentication

Smart authentication customize with internet access time setting and Ad push to promote brand or products.





AP Management

G3 can manage and monitor all the Tenda APs. The networking administrator can modify the description, SSID, channel, security for APs and monitor the APs and clients online status through G3.





Specifications:

Installation Desktop, rack installationDimensions (L*W*H) 294*178*44mmApplication Scenario Office, Home, School, Retail, CCTV, etc. Operation Mode Router ModeMax. Client Capacity 300Recommended Client Capacity 200Recommended Broadband 1000MbpsMax. New Sessions 3990Max. Concurrent Sessions 57000NAT (Static IP) 947.5Mbps/947.3MbpsNAT(DHCP) 947.1Mbps/947.6MbpsNAT(PPPoE) 918.6Mbps/916.4MbpsAP Management 100VLAN 4CPU Dual Core，1GHzRAM 512MBFLASH 16MB+128MBPorts 5*GE (Max. 4 WAN, Max. 4 LAN)Button Reset ButtonUSB 1*USBStandards and Protocols IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, DDNSPower Supply Build-in powerAP Management 100DHCP Server DHCP Server(User/AP)Wireless Policy SSID Policy, RF Policy, Vlan Policy, Fast Roaming 802.11k, v, rACL IP/MAC/URL/PORTBandwidth Control smart bandwidth controlVPN IPSec, PPTP, L2TPVirtual Server DMZ, DDNS, DNS Hijacking, IP Hijacking, UPNP, Port Mirroring, Port Mapping, DNS CacheWAN Load Balancing Intelligent Load Balancing, CustomizeRouting Static Routing, Policy RoutingSecurity IP-MAC binding, Block Ping from WANSystem Tools NTPSystem Log system logSystem Account Local，OnlineUpgrade Local, OnlineMaintenance Restore, Backup, Remote WEB ManagementManagement httpEnvironment Operating Temperature: -10℃-45°C
Operating Humidity:10%-90% RH, non-condensing
Storage Temperature: -40°C-70°C
Storage Humidity: 5%-90% RH, non-condensing
