TP-Link ER605W AC1350

TP-Link ER605W

Omada AC1200 Gigabit Wi-Fi Gateway

• AC120 0 Dual-Band WiFi (867 Mbps on 5 G + 300 Mbps on 2.4 G)*

• 5× Gigabit Ethernet Ports Provide High-Speed Connectivity

• 4× High-Ga in External Antennas for Boosted Coverage

• Load Balancing on up to 3× WAN Ports

• IPSec/PPTP/L2TP/Ope nVPN/WireGuard/GRE△ VPN

• DoS Defense, IP/MAC/URL Filtering, and More Abundant Security Features

• Centralized Cloud Management via Web and Omada App



Catego ry Feature DetailsSECURITY Access Control Source/Destination IP Based Access Control  Filtering Web Group Filtering△, URL Filtering, Web Security△  ARP Inspection Sending GARP Packets, ARP Scanning△, IP-MAC Binding  Attack Defense TCP/UDP/ICMP Flood Defense, Block TCP Scan (Stealth FIN/Xmas/Null), Block Ping from WANHARDWARE FEATURES Interface 1× Gigabit WAN, 2× Gigabit WAN/LAN, 2× Gigabit LAN  Button Reset Button  Power Supply 12V DC / 1A Power Adapter  Wi-Fi Frequency & Speed 2.4 GHz: 300 Mbps, 5 GHz: 867 Mbps  Flash 128 MB NAND  DRAM 256 MB DDR3  LED Indicators Power, SYS, 2.4G, 5G, WAN/LAN/LAN (1000/100/10M Link/Act)  Dimensions (W×D×H) 8.5 × 4.6 × 1.2 in (215 × 117 × 32 mm)  Antennas 2× 5 dBi (2.4 GHz), 2× 5 dBi (5 GHz), Non-detachable  Mounting Desktop / Wall-mounting  Max Power Consumption EU: 9W, US: 10.3WPERFORMANCE GRE Throughput Unencrypted: 180.1 Mbps, Encrypted: 56.9 Mbps  WireGuard VPN 71.2 Mbps  Concurrent Sessions 50,000  New Sessions / sec 2,028  NAT (Static IP) 909.3 / 937.5 Mbps  NAT (DHCP) 938.3 / 888.2 Mbps  NAT (PPPoE) 929.9 / 929.2 Mbps  NAT (L2TP) 346.9 / 337.6 Mbps  NAT (PPTP) 487.1 / 454.3 Mbps  OpenVPN 16.8 Mbps  L2TP VPN Throughput Unencrypted: 400.3 Mbps, Encrypted: 127.5 Mbps  PPTP VPN Throughput Unencrypted: 523.6 Mbps, Encrypted: 52.7 Mbps  66 Byte Packet Rate 1,453, 489 pps  1,518 Byte Packet Rate 81,275 ppsWIRELESS FEATURES SSIDs 16 Total (8 per radio)  Controls Enable/Disable Radio & SSID Broadcast, Transmit Power (dBm), Automatic Channel Selection  Enhancements Beamforming, Rate Limit (SSID/Client), Load Balance, Band Steering  Security WPA/WPA2 Personal & Enterprise, RADIUS Accounting, MAC Authentication  Scheduling Wireless Schedule, Reboot ScheduleBASIC FUNCTIONS WAN Type Static IP, Dynamic IP, PPPoE (with MRU), PPTP, L2TP  MAC Clone Modify WAN MAC  DHCP DHCP Server, DHCPv6 PD (Standalone), Address Reservation, Multi-IP, Multi-Net  IPv6 Static IP, SLAAC, DHCPv6, PPPoE, 6to4, PassThrough, Non-Address mode  VLAN 802.1Q VLAN  IPTV IGMP v2/v3 Proxy, Custom Mode, Bridge ModeADVANCED FEATURES Routing Static, Policy Routing, RIP, OSPF  Bandwidth Control IP-Based  Load Balancing Intelligent, Application Optimized, Link Backup (Timing, Failover), Online Detection  NAT One-to-One, Multi-Net, Virtual Server, Port Triggering△, NAT-DMZ, ALG (FTP, H. 323, SIP, IPSec, PPTP), UPnP  Session Limit IP-BasedVPN SUPPORT GRE Standalone Mode Only  IPsec VPN 6 Tunnels, LAN-to-LAN, Client-to-LAN, Negotiation: Main/Aggressive, AES (128/192/256), 3DES, DES, MD5/SHA Auth, NAT-T, DPD, PFS, IKEv1/v2  PPTP VPN Server & Client (6 Tunnels), MPPE Encryption  L2TP VPN Server & Client (6 Tunnels), L2TP over IPsec  OpenVPN Server & Client (3), 18 Tunnels, Certificate + Account Mode, Full Mode  WireGuard VPN SupportedAUTHENTICATION Web No Auth, Simple Password§, Hotspot (Local / Voucher§ / SMS§ / Radius§), External Radius, Portal§, LDAPMANAGEMENT Omada App Supported  Centralized Management Omada App, Hardware Controller, Software Controller  DDNS Dyndns, No-IP, Peanuthull, Comexe, Custom  Maintenance Web UI, Remote Mgmt, Export/Import Config, Ping/Traceroute△, NTP Sync△, Port Mirroring, Syslog  Features Auto Device Discovery, Network Monitoring, Alerts, Unified Config, Reboot Schedule, Captive PortalOTHER Default Services Web Server (Port: 80/443, TCP), TDP Discovery (Port: 20003, UDP), DHCP Server (Port: 67, UDP), DNS (Port: 53, TCP/UDP)
