TP-Link MB115-4G

300 Mbps Wireless N 4G LTE Router

• 4G network – Share internet access with up to 32 Wi-Fi devices and enjoy download speeds of up to 150 Mbps
• Plug a SIM card and play – No configurations needed, compatibility of SIM cards are assured by years of field tests*
• 300 Mbps WiFi – Fast WiFi speeds up to 300 Mbps to share your network.
• Maximum Network Coverage – Enjoy stable and efficient connections to every device thanks to the four external antennas
• Wi-Fi router mode – Plug an Ethernet cable into the LAN/WAN port for flexible access if you can't get a 4G connection





Plug Your Nano SIM Card and Play

Fully compatible with FDD-LTE and TDD-LTE for use with most service providers worldwide. Insert a nano SIM card and turn on the router to share your 4G LTE network with multiple WiFi devices.





Superfa st 4G LTE Speed for Reliable Wi-Fi

MB115-4G harnesses 4G LTE technology to deliver lightning-fast download speeds of up to 150 Mbps and up to 50 Mbps for uploads. It also shares a WiFi network with a max speed of 300 Mbps on 2.4 GHz—perfect for gaming, streaming, and more.







Specifica tion DetailsNetwork Type (EU) FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz); TDD-LTE: B38/B40 (2600/2300 MHz); HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)Network Type (CN) FDD-LTE: B1/B3/B5/B8 (2100/1800/850/900 MHz); TDD-LTE: B38/B40 (2600/2300 MHz); HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)Network Type (UN) FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B28/B66 (2100/1900/1800/1700/850/2600/900/700/17 00 MHz); TDD-LTE: B40 (2300 MHz); HSPA+/UMTS: B1/B2/B4/B5/B8 (2100/1900/1700/850/900 MHz)Wi-Fi Class N300Wi-Fi (2.4 GHz) 300 MbpsWireless Standards IEEE 802.11b/g/nFrequency 2.4 GHzReception Sensitivity 11g 54M: -74.5 dBm; 11n HT20 MCS7: -73.5 dBm; 11n HT40 MCS7: -70.5 dBmTransmission Power < 20 dBm (2.4 GHz)Wireless Security WPA-PSK / WPA2-PSKWireless Functions Smart Connect, WPS, Wireless Schedule, Wireless Clients StatisticsDimensions 219 × 140 × 32 mm (8.62 × 5.51 × 1.26 in)Interfaces 1× 10/100Mbps LAN/WAN Port; 3× 10/100Mbps LAN Ports; 1× Nano SIM Card SlotAntenna 2× External 4G LTE Antennas; 2× External Wi-Fi AntennasButton WPS, Reset ButtonExternal Power Supply 9V/0.85ALED 1× Power; 1× Internet; 1× LAN; 3× SignalLTE Standard Cat 4, 150/50 Mbps DL/ULOperation Mode 3G/4G Router, Wireless RouterCellular Mode 4G Preferred, 4G Only, 3G OnlyCellular APN Data Roaming, Network Search, Profile Create, APN Settings, ISP File Upgrade, PIN ManagementWAN Mode Dynamic IP, Static IP, PPPoE, PPTP, L2TPNAT Forwarding ALG, Virtual Server, Port Triggering, UPnP, DMZProtocols IPv4, IPv6Data Settings Data Statistics, Data LimitParental Controls Time Control, Website FilteringGuest Network 2.4 GHz Guest NetworkDHCP Server, DHCP Client List, Address ReservationDDNS MERCUSYS DDNS, DynDns, NO-IPSMS Inbox, New Message, Outbox, DraftsSecurity IPv4 SPI Firewall, Access Control, Service Filtering, IP & MAC Binding, IPv6 FirewallSystem Settings Time Settings, LED Control, Diagnostics, Firmware Upgrade, Backup & Restore, Reboot, Administration, System Log, CWMP SettingsDevice Management MERCUSYS APP, Web GUISystem Language English, Spanish, Italian, Polish, RussianTR-069 √
