TRENDnet TWG-431BR

Стандарти
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.1Q

Интерфейс

5 x Gigabit ports (Modes: 4 WAN ports / 1 LAN port or 1 WAN port / 4 LAN ports)
1 x USB 3.0 port (Backup & Restore Configuration / Export Logging)
1 x RJ-45 console port
Reset button
LED indicators
On/off switch

Производителност

NAT (LAN-to-WAN) Throughput: 900Mbps
Routing Performance: 900Mbps
Maximum Concurrent Sessions: 50,000
Maximum Number of VLANs: 8 (ID: 1-4093)
IPsec VPN (AES-256/SHA-256/LAN-to-LAN) Throughput: 200Mbps
SSL VPN Throughput (Blowfish/SHA-1/Bridge): 20Mbps
VPN
SSL VPN Client-to-Site (Up to 30 tunnels)
IPsec VPN Site-to-Site / Client-to-Site (Up to 40 tunnels)
PPTP/L2TP VPN Server / Client-to-Site (Up to 40 tunnels)
L2TP with IPsec VPN Server / Client-to-Site (Up to 40 tunnels shared with L2TP)
IPsec Encryption: 3DES, AES-128/192/256
IPsec Authentication: MD5, SHA-1, SHA-256
IPsec Key Exchange: IKE: Main/Aggressive Mode, Pre-shared Key, DH Groups 1/2/5/14
IPsec Protocols: ESP, PFS DH Groups 1/2/5/14, DPD, Local/Remote ID: IP Address, FQDN
IPsec NAT Traversal
SSL VPN Encryption: AES
SSL VPN Certificate: RSA
PPTP/L2TP Encryption: MPPE 40-bit, 128-bit, IPsec
PPTP/L2TP Authentication: MS-CHAPv1/2
Networking
WAN Modes: NAT, Classical Routing
NAT Modes: NAT, PAT
IPv4 WAN Modes: DHCP, Static IP, PPPoE, PPTP
IPv6 WAN Modes: Static, Auto-configuration (SLAAC/DHCPv6), Link-Local, PPPoE, 6to4, 6rd
Routing: Static, dynamic RIPv2, OSPFv1/2, distribute RIPv2 over OSPFv1/2, routing policies (Up to 20 entries)
Inter-VLAN Routing (Up to 8 VLANs, 8 IP interfaces)
DHCP Server/Relay
Dynamic DNS: dyn. com, no-ip. com
WAN Failover
WAN Load Balancing: Assign weight by percentage or bandwidth, source IP based, source & destination IP based, session based
High Availability: Supports 1 active-passive cluster up to a total of 6 units (1 master + 5 standby)
VPN passthrough: IPsec, PPTP, L2TP
Access Control
MAC address filtering (Up to 64 entries)
IP address filtering: TCP, UDP, ICMP (Up to 64 entries)
Content filtering: URL (HTTP only), Keyword, P2P, IM (Up to 64 entries)
Virtual server/port forwarding (Up to 64 entries)
Advanced web content filtering service powered by Router Limits
Scheduling: IP/MAC/Content filters, virtual server (Up to 10 entries)
DMZ host
Quality of Service
Bandwidth Control: applicable by IP network, IP range, TCP/UDP port, SIP, RTSP, RTP, web
Управление
CLI (Console/Telnet/SSHv2) command line management
HTTP/HTTPS (SSL v2/3 TLS) web based management, upload custom SSL certificate
SNMP v1, v2c, v3
SNMP trap (Up to 4 receivers)
Scheduled automatic reboot
Scheduled Wake-on-LAN (WoL) to remote network device
Internal logging or send logging to external syslog server
Manual or online firmware upgrade and notification
Backup and restore configuration
Diagnostic tools: Built-in ping & traceroute network utilities
MIB
MIB II RFC 1213

Захранване

Input: 100 – 240V AC, 50/60Hz, 0.5A
Output: 12V DC, 1.5A external power adapter
Max. consumption: 17.4W

Работна температура
0 – 50°C (32 – 122°F)

Максимална влажност
Max. 80% non-condensing

Сертификати
CE
FCC

Размери
265 x 185 x 44.45mm (10.4 x 7.28 x 1.75 in. )

Rack mountable 1U height
0710931301410
