ZOTAC GeForce RTX 5050 Twin Edge White Edition OC 8GB GDDR6 128bit (ZT-B50500Q-10M)

ZOTAC GAMING GeForce RTX 5050 Twin Edge
ZT-B50500Q-10M

The ZOTAC GAMING GeForce RTX 5050 Twin Edge is a compact graphics card powered by NVIDIA‘s cutting edge Blackwell Architecture, DLSS4 and 8GB of GDDR6 memory. Powerful and compact, the Twin Edge is ready to take on games with smooth framerates and performance.

Feature Highlights:
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- 8-Pin PCIe power connector
- SFF-Ready Graphics Card
- Compact dual-fan form factor
- BladeLink Fans
- Metal Backplate
- All-new FireStorm Utility

The compact design of the ZOTAC GAMING GeForce RTX 5050 Series of GPUs are SFF-ready, making it easier for gamers looking to upgrade. With a slim 2-slot width and as compact as 164.5mm (6.5 inches) in length, most PC cases available can easily accommodate with a simple drop-in installation.

STANDARD 8-PIN POWER
A single 8-pin PCIe power connector is all that’s needed to power this GPU. A lower 550W minimum recommended power supply (PSU) means that there are potentially less components needed for an upgrade, making the 5050 Series a more appealing upgrade choice.

BLADELINK FANS
Optimized airflow intake
Reinforced structure rigidity

METAL BACKPLATE
The ZOTAC GAMING GeForce RTX 5050 Series rigidity is achieved with a metal backplate, giving it a strong foundation in durability.

Specifications

GPU
NVIDIA GeForce RTX 5050 GPU

CUDA cores
2560

Video Memory
8GB GDDR6

Memory Bus
128-bit

Engine Clock
2572 MHz

Memory Clock
20 Gbps

PCI Express
PCI Express 5.0 x8

Display Outputs
3 x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz or 8K 165Hz with DSC)
1 x HDMI® Connector (Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate as specified in the HDMI 2.1b Specification)


HDCP Support
2.3

Multi Display Capability
Quad Display

Recommended Power Supply
550W

Power Consumption
130W

Power Input
1 x 8-pin power input

DirectX
Microsoft DirectX 12 Ultimate

OpenGL
4.6

Cooling
Fans + Heatsink

Slot Size
2

SLI
No

Supported OS
Windows 11 / Windows 10 64-bit (v1809 November 2018 or later)

Card Length
220.5mm x 120.25mm x 41.6mm / 8.7" x 4.7" x 1.6"
