Zyxel USGFLEX100H-EU0101F

ZyXEL USG FLEX 100H

Secure. Fast. Protection.

Ultra-high Performance powered by our next-generation multi-core hardware and Fastpath technology to create ultra-high efficiency. The USG FLEX H series can boost performance by up to 3x, optimizing utilization of its processors and allowing Zyxel to deliver superior performance to satisfy the needs required by demanding and high-speed networks.

With 2.5 Gbps and 10 Gbps Port Speed options, The USG FLEX H also features software-defined ports, allowing you true flexibility in the configuration and tailoring of each USG FLEX H as required (WAN or LAN).

The USG FLEX H offers up to 2 x 30W PoE+ integrated ports*1 to help reduce complexity by simplifying installations and reduce install costs by allowing you to power devices like 5G Routers, latest WiFi, or appliances like VoIP Phones directly from the USG FLEX H itself.

Interface ports

100H:

8 x 1GbE

100HP:

7 x 1GbE

1 x 1GbE/PoE+ (802.3at, 30W max. )

USB 3.0 ports

1

Console port

Yes (RJ-45)

Rack-mountable

-

Fanless

Yes

SPI firewall throughput (Mbps)

4,000

VPN throughput (Mbps)

900

IPS throughput (Mbps)

1,500

Anti-Malware throughput (Mbps)

1,000

UTM throughput (Anti-malware & IPS, Mbps)

1,000

Max. TCP concurrent sessions

300,000

Max. concurrent IPsec VPN tunnels

50

Recommended gateway-to-gateway IPsec VPN tunnels

20

Concurrent SSL VPN users

25

VLAN interface

16

Anti-Malware

Yes

IPS

Application Patrol

Yes

Web filtering

Yes

Reputation Filter

Yes

SecuReporter

Sandboxing

Yes

S ecurity Profile Sync

Yes

Device Insight

Yes

Secure WiFi*8

Yes

VPN

IKEv2, IPSec, SSL

SSL (HTTPS) inspection

Yes

Two-Factor Authentication

Yes

Nebula Centralized Management

Yes

Power input

100H: 12V DC, 2A max.

100HP: 19V DC, 3.42A

Max. power consumption (Watt Max. )

100H: 17

100HP: 51.2

Heat dissipation (BTU/hr)

100H: 40.365

100HP: 194.5

PoE power budget (watt max. )

100HP: 30

Item

Dimensions (WxDxH)(mm/in. ):

216 x 143 x 33/8.50 x 5.80 x 1.30

Weight (kg/lb. ):

100H: 1.04/2.29

100HP: 1.05/2.31

Packing

Dimensions (WxDxH)(mm/in. ):

278 x 189 x 99/10.94 x 7.44 x 3.89

Weight (kg/lb. ):

100H: 1.62/3.57

100HP: 1.91/4.21

Included accessories

Power adapter

Power cord (100HP)

RJ-45 - RS-232 cable for console connection

Operating

Temperature: 0°C to 40°C / 32°F to 104°F

Humidity: 10% to 90% (non-condensing)

Storage

Tem perature: -30°C to 70°C / -22°F to 158°F

Humidity: 10% to 90%(non-condensing)

MTBF (hr)

100H:

40°C/ 289845.2327 hr

25°C/ 518347.4294 hr

100HP:

40°C/ 291183.7887 hr

25°C/ 550382.5753 hr
