Item no.

EV2457-BK
Case colours

Black
Solutions Office, Gaming
Product line
FlexScan

RadiCS application classes VIII
Screen size [in inches]

24.1
Screen size [in cm]

61
Format

16:10
Viewable image size (width x height) 518 x 324
Ideal and recommended resolution

1920 x 1200
Pixel Pitch Horizontal [mm] 0.270 x 0.270
Resolution Supported 1920 x 1200, 1600 x 1200, 1680 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 720 x 400, 640 x 480
Panel technology

IPS
Max. viewing angle horizontal

178°
Max. viewing angle vertical

178°
Number of colours or greyscale 16.7 million colours (display port, 8 Bit), 16.7 million colours (HDMI, 8 Bit), 16.7 million colours (DVI, 8 Bit)
Max. colour space sRGB
Max. brightness (typical) [in cd/m2]

350
Max. dark room contrast (typical) 1000:1
Typical response time [grey/grey alternation]

5ms
Max. refresh rate [in hertz] 60
Backlight

LED
Colour palette / look-up table

1.06 billion colour tones / 10 Bit
Overdrive
No flickering thanks to hybrid controls
Signal range amplifier (HDMI)
HDCP Decoder
Preset colour/greyscale modes sRGB, Paper, Movie, DICOM, 2x free modes for user selection
DICOM tone curve
OSD language de, en, fr, es, it, se, ja, zh
Adjustment options Brightness, Contrast, Gamma, All EcoView functions, Colour saturation, Colour temperature, FineContrast, Colour tone, Signal input, Overdrive, Resolution, Audio source, Sharpness, OSD language, Interpolation, Volume
Button Guide
Signal inputs DisplayPort, DVI-D, HDMI
Signal outputs for daisy chain compatibility DisplayPort
Video Signal DisplayPort, DVI (TMDS), HDMI (YUV, RGB)
Frequency

Display Port: 31-76 kHz/59-61 Hz; DVI-D: 31-76 kHz/59-61 Hz; HDMI: 15-76 kHz/49-61 Hz
Input Signal Identification
Audio Input 3.5 mm stereo jack, DisplayPort, HDMI
Audio Output 3.5 mm stereo jack
Built-in speakers
USB hub

1 Up-/ 4 Down-Stream, Rev. 3.1
Power consumption (typical) [in watt]

11
Maximum Power Consumption [in watt] 59 ( at maximum brightness with all signal inputs and USB ports in use)
Power Save Mode [in watt]

0.5
Power Consumption Off [in watt]

0
Energy-efficiency class

A++
Auto-EcoView
EcoView-Index
EcoView-Optimiser
Power Supply

AC 100-240V, 50/60Hz
Power Management DVI-DMPM, DisplayPort Version 1.2a
Integrated power unit
Dimensions [mm]

531 x 353-510 x 190
Weight [in kilograms]

5.8
Dimensions Without Stand [mm]

531 x 344 x 46
Weight Without Stand [in kilograms]

3.8
Swivel (right/left)

172°
Incline forward/backward 5 ° / 35 °
Pivot 90°
Height Adjustment Range [mm]

158.6
Hole Spacing

VESA standard 100 x 100 mm
Certification CE, TÜV/GS, TÜV/Ergonomics, TCO 8, Energy Star, ISO 9241-307 Klasse 1**, TÜV/Low blue light content, TÜV/Flicker Free, RCM, CB, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, RoHS, WEEE, CCC, EAC
Accompanying software and other
accessories are available for
download or on a CD Screen InStyle
Additional Supply Power cord, Signal cable DisplayPort - DisplayPort, Quick guide, USB cable, Cable protection
Accessory EIZO ScreenCleaner (for the best possible clean without scratching the monitor), HH200HS-K (HDMI (High Definition Multimedia Interface) cable to transfer digital video and audio signals. ), PM200-K (DisplayPort cable to transfer digital video and audio signals. ), PP100-K (Short DisplayPort connection cable (100 cm) to transmit digital audio and video signals ), PCSK-03-WT (Thin Client Mount for the EIZO FlexStand 4 Stand)
Warranty and service 5 years including on-site replacement service
Terms **) Zero pixel error guarantee for completely lit sub-pixels (partial pixels ISO 9241-307). Valid: six months from the purchase date.
