Device Type: Switch - 12 ports - ManagedEnclosure Type: Rack-mountable 1USubtype: Gigabit EthernetPorts: 12 x 10/100/1000 (PoE+) + 2 x Gigabit SFP + 2 x 1000Base-TPower Over Ethernet (PoE): PoEPoE Budget: 139 WPerformance: Packet buffer size: 12.38 MB
Throughput: 23.8 Mpps
Switching capacity: 32 Gbps
Latency (1 Gbps): 2.3 s
Latency (10 Gbps): 2.6 sCapacity: Switched virtual interfaces (SVIs): 16
ARP entries: 1024
IPv4 routes (Unicast): 512
IPv6 routes (Unicast): 512
IGMP groups: 512
MLD groups: 512
IPv4 ACL entries (ingress): 256
IPv6 ACL entries (ingress): 128
MAC ACL entries (ingress): 256MAC Address Table Size: 8192 entriesJumbo Frame Support: 9198 bytesRouting Protocol: IGMPv2, IGMPv3Remote Management Protocol: SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, RADIUSEncryption Algorithm: SSLAuthentication Method: Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v. 2 (SSH2)Features: Flow control, BOOTP support, ARP support, VLAN support, DiffServ support, IPv6 support, SNTP support, sFlow, Multiple Spanning Tree Protocol (MSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, MLD snooping, Trusted Platform Module (TPM), fanless, LACP support, LLDP support, DHCP client, Management Information Base (MIB), Neighbor Discovery Protocol (NDP), SNMP support, Internet Control Message Protocol (ICMP), DNS client, LLDP-MED, User Datagram Protocol (UDP), Rapid Reconfiguration of Spanning Tree (RSTP), IPv6 addressingCompliant Standards: IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.3at, IEEE 802.3azProcessor: 1 x ARM A9: 1.016 GHzRAM: 4 GB DDR3 SDRAMFlash Memory: 16 GBInterfaces: 12 x 10/100/1000 Base-T RJ-45 PoE Class 4 - 139 W
2 x 10Gbit LAN SFP
2 x Gigabit LAN
1 x USB Type A
1 x USB-C consolePower Device: Internal power supplyVoltage Required: AC 100-240 V (50/60 Hz)Power Consumption Operational: 21.9 WattCompliant Standards: CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, CAN/CSA C22.2 No. 60950, CNS 13438, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, VCCI-CISPR 32:2016 Class A, CISPR 35, EN 55035:2017, EN 55032:2015/AC:2016-07 Class A, EN55024:2010:A1, IEC 62368-1 Second EditionWidth: 25.4 cmDepth: 25.5 cmHeight: 4.39 cmWeight: 2.78 kgService & Support: Limited warranty - lifetimeMin Operating Temperature: 0 °CMax Operating Temperature: 45 °CHumidity Range Operating: 15 - 95% (non-condensing)Humidity Range Storage: 15 - 90% (non-condensing)

Продукт известен още и като Aruba 6000 12 G R 8 N 89 A, Aruba600012GR8N89A, Aruba 6000 12G (R8N89 A)
