Lian Li O11 Dynamic Mini V2 Flow black

O11 DYNAMIC MINI V2

• Precision resized 45.38L chassis offers expanded hardware support with a compact footprint
• Pillar-less tempered glass front and side panels for an unobstructed internal view
• 10° slanted bottom improves GPU airflow and aesthetic presentation
• Supports ATX, M-ATX, Mini-ITX, and ATX Back-Connect motherboards
• Accommodates 400mm long GPUs, 160mm tall CPU coolers, and ATX PSU (Under 200mm)
• Supports up to 360mm top radiator, 240mm side radiator, and 9 x 120mm fans
• Includes horizontal and vertical GPU anti-sag brackets for heavy GPU support







SLIGHTLY BIGGER CASE, WAY MORE CAPACITY

Only 2L larger than the original O11D Mini, but redesigned for greater hardware compatibility and improved airflow.



ATX BACK-CONNECT MOTHERBOARD SUPPORT

The case offers broad motherboard support, including standard ATX, M-ATX, and Mini-ITX form factors. For users seeking next-level cable management and cleaner builds, Back-Connect compatibility is exclusively available with ATX Back-Connect motherboards.



ANGLED BASE FOR DIRECT GPU AIRFLOW

A 10° slanted bottom channels cool air directly to the GPU for better cooling performance and a cleaner look.



ADJUSTABLE MOTHERBOARD STANDOFFS FOR RADIATOR FLEXIBILITY

This case features movable motherboard standoffs, allowing vertical adjustment of the M-ATX mounting position. This flexibility enhances compatibility with 280mm radiators, as well as thicker 360mm or 240mm models.



GPU ANTI-SAG SUPPORT

Horizontal and Vertical GPU brackets are included out of the box, giving users the freedom to choose their GPU orientation.



ADJUSTABLE ANTI-SAG BRACKET FOR VERTICAL GPU

The vertical GPU support bracket features height adjustment to accommodate thick cards and prevent GPU sag.



Specification DetailsColor Options BlackDimensions (D × W × H) 423.6 mm × 273.3 mm × 391.95 mmMaterials 2mm Aluminum Panel / 1mm Mesh Panel / 4.0mm Tempered GlassMotherboard Support Back-Connect ATX / ATX / Micro-ATX / Mini-ITXExpansion Slots 5Storage Support Drive Cage: 2 × 2.5 SSD or 2 × 3.5 HDDBehind MB Tray: 2 × 2.5 SSDGPU Length Clearance 400 mmCPU Cooler Height Clearance 160 mmPSU Support ATX (Under 200 mm)Radiator Support Top: 240 mm / 280 mm / 360 mm (280 mm requires motherboard mounted one slot lower)Side: 240 mmFan Support Top: 3 × 120 mm or 2 × 140 mmSide: 2 × 120 mmBottom: 3 × 120 mmRear: 1 × 120 mmIncluded Fans Side: 2 × Reverse Blade 120 mm PWMBottom: 3 × Reverse Blade 120 mm PWMDust Filters Bottom × 1
