UNI-T UT107+ Automotive Multimeter
UT107+ Automotive Multimeter
Подобни продукти
Описание на продукта
UT107+ Automotive Multimeters have updated measurement functions, accuracy, and meter shell to test conventional and hybrid vehicles. This series contains all the reliable functions...
Параметри на продукта
Производител
UNI-T
Етикет
UNI-T
Параметри на продукта
Производител
UNI-T
Етикет
UNI-T
Описание на продукта
UT107+ Automotive Multimeters have updated measurement functions, accuracy, and meter shell to test conventional and hybrid vehicles. This series contains all the reliable functions of the traditional multimeter and offers RPM, dwell angle, pulse width, and battery test as well.
1000V AC/DC voltage and 10A AC/DC current (20A for 10s max) measurement range is suitable for most of the vehicle and electrical facilities maintenance. Up to 1000V VFC mode enables users to take accurate measurements on variable-frequency motor drives, water pumps, HVAC systems.
UT107+ is True RMS automotive multimeters that meet CAT II 1000V/CAT III 600V safety rating. UT105+ is designed for basic vehicle troubleshooting with 4000 counts display. UT107+ supports some extra functions, such as battery test, pulse width, capacitance with 6000 counts display.
Specifications Range UT107+
600mV/6V/60V/600V/1000V±(0.5%+3)
6V/60V/600V/1000V±(0.8%+3)
6mA/60mA/600mA/10A (20A for 10s max)±(1.0%+8)
6mA/60mA/600mA/10A (20A for 10s max)±(0.8%+8)
600/6K/60K/600K/6M/60M±(0.8%+3)
Capacitance (F) 6nF/60nF/600nF/6uF/60uF/600uF/6mF/60mF/ 100mF ±(3%+10)
Frequency (Hz) 10Hz~10MHz ±(0.1%+5)
Temperature (℃) -40℃~1000℃ ±(1.0%+3)
Temperature (℉) -40℉~1832℉ ±(1.5%+5)
VFC 1000V ±(2.0%+10)
RPM 2STR ±(3.0%+5)
4STR ±(3.0%+3)
Dwell angle 1CYL(0～356.4°)/2CYL(0～178.2°)/3CY L(0～118.8°)/4CYL(0～89.1°)/5CYL(0
1000V AC/DC voltage and 10A AC/DC current (20A for 10s max) measurement range is suitable for most of the vehicle and electrical facilities maintenance. Up to 1000V VFC mode enables users to take accurate measurements on variable-frequency motor drives, water pumps, HVAC systems.
UT107+ is True RMS automotive multimeters that meet CAT II 1000V/CAT III 600V safety rating. UT105+ is designed for basic vehicle troubleshooting with 4000 counts display. UT107+ supports some extra functions, such as battery test, pulse width, capacitance with 6000 counts display.
Specifications Range UT107+
600mV/6V/60V/600V/1000V±(0.5%+3)
6V/60V/600V/1000V±(0.8%+3)
6mA/60mA/600mA/10A (20A for 10s max)±(1.0%+8)
6mA/60mA/600mA/10A (20A for 10s max)±(0.8%+8)
600/6K/60K/600K/6M/60M±(0.8%+3)
Capacitance (F) 6nF/60nF/600nF/6uF/60uF/600uF/6mF/60mF/ 100mF ±(3%+10)
Frequency (Hz) 10Hz~10MHz ±(0.1%+5)
Temperature (℃) -40℃~1000℃ ±(1.0%+3)
Temperature (℉) -40℉~1832℉ ±(1.5%+5)
VFC 1000V ±(2.0%+10)
RPM 2STR ±(3.0%+5)
4STR ±(3.0%+3)
Dwell angle 1CYL(0～356.4°)/2CYL(0～178.2°)/3CY L(0～118.8°)/4CYL(0～89.1°)/5CYL(0
