Chipset
AMD B550

CPU
Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series desktop processorsSocket AM4

Memory
4x DDR4, Maximum Memory Capacity 128GBMemory Support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400+ MHz by A-XMP OC MODEMax. overclocking frequency: 1DPC 1R Max speed up to 4400+ MT/s 1DPC 2R Max speed up to 3733+ MT/s 2DPC 1R Max speed up to 3866+ MT/s 2DPC 2R Max speed up to 3466+ MT/sSupports JEDEC SpeedSupports Dual-Channel modeSupports non-ECC, un-buffered memorySupports Memory Overclocking by A-XMP OC mode The DIMM slots on this motherboard have double-sided latches. Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support page or visit https://www. msi. com/support/.

Onboard Graphics
1x HDMISupport HDMITM 2.1, maximum resolution of 4K 60Hz*1x DisplayPortSupports DP 1.4, maximum resolution of 4K 60Hz*1x VGASupport VGA, maximum resolution of 2048x1536 50Hz, 1920x1200 60Hz**Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

Slot
1x PCI-E x16 slot2x PCI-E x1 slotPCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)*The supported specification depends on installed processor.

Audio
Realtek® ALC897 Codec7.1-Channel High Definition Audio

Storage
2x M. 2M. 2_1 Source (From CPU) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devicesM. 2_2 Source (From Chipset) supports up to PCIe 3.0 x4 , supports 2280/2260/2242 devices4x SATA 6G*The supported specification depends on installed processor.

RAID
Supports RAID 0, RAID 1, and RAID 10 for SATA storage devicesSupports RAID 0 and RAID 1 for M. 2 NVMe storage devices

USB
2x USB 2.0 (Rear)4x USB 2.0 (Front)4x USB 5Gbps Type A (Rear)2x USB 5Gbps Type A (Front)1x USB 5Gbps Type C (Front)

LAN
Realtek® RTL8111H 1Gbps LAN

Internal IO
1x Power Connector(ATX_PWR)1x Power Connector(CPU_PWR)1x CPU Fan2x System Fan2x Front Panel (JFP)1x Chassis Intrusion (JCI)1x Front Audio (JAUD)1x Com Port (JCOM)2x Addressable V2 RGB LED connector (JARGB_V2)2x RGB LED connector(JRGB)1x TPM pin header(Support TPM 2.0)4x USB 2.0 ports2x USB 5Gbps Type A ports1x USB 5Gbps Type C ports

LED FEATURE
4x EZ Debug LED

BACK PANEL PORTS
VGAUSB 5Gbps Type-AKeyboard / MouseLAN PortAudio connectorsDisplayPortHDMIUSB 2.0USB 5Gbps Type-A

OPERATING SYSTEM
Support for Windows® 11 64-bit, Windows® 10 64-bit

BOX CONTENT


PCB Info
mATX243.84mmx243.84mm
