Zalman Chronix V2 black

Zalman Chronix V2



Modern & Sleek Design

The Chronix combines style and functionality, offering a clean, streamlined look that complements any setup while ensuring optimal performance and ease of use.

Panoramic View

With Seamless Tempered Glass Panels

Tool-Free Glass Panels

The Front and Side panels can be easily and completely removed for convenient access to PC components



* Easy panel management with groove fixing structure at the bottom of the tempered glass

Optimal Airflow

Two 120mm reverse fans on the side effectively pull fresh air from the outside into chassis, while the rear fan blows hot air out to maximize air flow and cooling performance.



Enhanced airflow design with top, bottom and back mesh panels for effective cooling and heat dissipation

Pre-installed ARGB

Infinity Mirror Fans

Comes with three pre-installed 120mm addressable RGB fans, delivering stunning visuals and full customization for your gaming PC

Mesh Bottom Panels

The full mesh bottom panel ensures excellent airflow, enhancing cooling and preventing overheating while minimizing dust buildup for cleaner, more efficient performance.





Vibrant ARGB Lighting Effect



6 -Channel ARGB/PWM Hub

 6-Ports Hub for Dynamic ARGB  Lighting and Precise Fan Speed Control



ARGB fans with PWM

 ARGB fans with infinity mirrors and RGB line design

 Smart Cooling with PWM



Dimensions : 120 x 120 x 25(T)mm

Rated Voltage :  Fan (DC 12V) / LED (5V) 0.28A

Max. Fan Speed : 800 ~ 1,500 ± 10%

Max. Fan Noise Level: Side 29dB(A) / Rear 25.5dB(A)

Bearing Type : Hydraulic Bearing

Outstanding Expandability and User Convenience

Motherboard Support

Efficient Cable Management with Optimal Routing Design

Cable management space helps keep wires organized. Convenient cable management layout and space makes it easier than ever to organize messy cables for a clean look

Easy Accessible I/O ports

a) USB Type-C

b) USB 3.0

c) USB 2.0

d) Microphone / Headphone Jack

e) LED Button

f) Power Button

Rear Layout

1. Side Thumbscrews

2. Rear 120mm ARGB Fan(Included)

3. Side Handle

4. 7 PCI Slot

5. PSU Space



Specifications



Case Form Factor ATX Mid-TowerMaterials Steel, Plastic , Tempered GlassWeight 6.1kgDimensions 436(L) x 215(W) x 487(H) mmMotherboard Support ATX / mATX / Mini-ITXFan Support Top : 3 x 120mm / 2 x 140mm
Side : 2 x 120mm
Rear : 1 x 120mm
Bottom : 3 x 120mmFan(s) Included Side : 2 x 120mm (Reverse ARGB Fan)
Rear : 1 x 120mm (ARGB Fan)Radiator Support Top : 120mm/ 140mm / 240mm/ 280mm / 360mm
Side : 120mm / 240mm
Rear : 120mmMax. PSU Length 200mmMax. VGA Length 410mmMax. CPU Cooler Height 165mmDrive Bays 1 x Combo (3.5’’ or 2.5’’), 1 x 3.5’’HDD, 2 x 2.5’’SSDPCI Expansion Slots 7 pcsI/O Ports Power, Reset & LED, HD Audio, 1 x USB 2.0, 1 x USB 3.0, 1 x USB Type-C(5Gbps )
