MSI H510M PRO-E

MSI H510M PRO E

PRO series helps users work smarte rby delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.



FROZR AI COOLING

Detecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE.



Performance mode

Silent mode

Manuel mode

EZ DEBUG LED

Ran into trouble? Onboard LEDs for key components will indicate the source of the problem so you know exactly where to look to get it up and running again.

Secure Boot

Secure boot is a security standard to make sure that a device boots using only software that is trusted. When the PC starts, the firmware checks the signature of each piece of boot software, including UEFI firmware drivers, EFI applications, and the operating system. The PC boots while the signatures are valid.

Transfer lots of data, music and movies over USB easier. USB 3.2 Gen 1 ports are ready in both front and rear IO, provides wide variety of options to connect your USB 3.2 Gen 1 devices.



Specification





PROCESSOR

Supports 10th Gen Intel® Core Processors, 11th Gen Intel® Core Processors, Pentium® Gold and Celeron® Processors1

CHIPSET

Intel® H510 Chipset

MEMORY

2x DDR4 memory slots, support up to 64GB1

Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU (by JEDEC & POR)

Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel® CPU (by JEDEC & POR)

Supports Dual-Channel mode

Supports non-ECC, un-buffered memory

Supports Intel® Extreme Memory Profile (XMP)

 Please refer to www. msi. com for more information on compatible memory.

See supported memory

EXPANSION SLOT

1x PCIe x16 slot (From CPU)

Support up to PCIe 4.0 for 11th Gen Intel® CPU

Support up to PCIe 3.0 for 10th Gen Intel® CPU

2x PCIe 3.0 x1 slots (From PCH)

ONBOARD GRAPHICS

1x VGA port, supports a maximum resolution of 2048x1536 60Hz, 1920x1200 60Hz

1x HDMI 1.4 port, supports a maximum resolution of 4K 30Hz 1 2

 Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

STORAGE

4x SATA 6Gb/s ports (From H510 Chipset)

USB

Intel® H510 Chipset

4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)

6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector)

AUDIO

Realtek® ALC897 Codec

7.1-Channel High Definition Audio

LAN

1x Realtek® RTL8111 Gigabit LAN controller

INTERNAL CONNECTORS

1x 24-pin ATX main power connector

1x 8-pin ATX 12V power connector

4x SATA 6Gb/s connectors

1x USB 3.2 Gen 1 5Gbps connector (support additional 2 USB ports)

1x USB 2.0 connector (support additional 2 USB ports)

1x 4-pin CPU fan connector

1x 4-pin system fan connector

1x Front panel audio connector

2x System panel connectors

1x Serial port connector

1x Chassis Intrusion connector

1x Clear CMOS jumper

1x TPM module connector

DIMENSIONS

mATX Form Factor

9.3 x 7.5 in. (23.6 cm x 19.0 cm)

MOUNTING

6 mounting holes

OPERATING SYSTEM

Support for Windows® 10 64-bit
