Описание на продукта
Chipset AMD B550 CPU Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series desktop processorsSocket AM4 Memory 2x DDR4, Maximum Memory...
Параметри на продукта
Параметри на продукта
Описание на продукта
Chipset
AMD B550
CPU
Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series desktop processorsSocket AM4
Memory
2x DDR4, Maximum Memory Capacity 64GBMemory Support DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODEMax. overclocking frequency: 1DPC 1R Max speed up to 4600+ MHz 1DPC 2R Max speed up to 3866+ MHzSupports JEDEC SpeedSupports Dual-Channel modeSupports non-ECC, un-buffered memorySupports Memory Overclocking by A-XMP OC mode The DIMM slots on this motherboard have double-sided latches. Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support page or visit https://www. msi. com/support/.
Onboard Graphics
1x HDMISupport HDMITM 2.1, maximum resolution of 4K 60Hz*1x DisplayPortSupports DP 1.2, maximum resolution of 4K 60Hz**Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Slot
1x PCI-E x16 slotPCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)*The supported specification depends on installed processor.
Audio
Realtek® ALC897 Codec7.1-Channel High Definition Audio
Storage
2x M. 2M. 2_1 Source (From CPU) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devicesM. 2_2 Source (From Chipset) supports up to PCIe 3.0 x4 , supports 22110/2280 devices4x SATA 6G*The supported specification depends on installed processor.
RAID
Supports RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage devices*Supports RAID 0, RAID 1, and RAID 10 for M. 2 NVMe storage devices
USB
2x USB 2.0 (Rear)4x USB 2.0 (Front)4x USB 5Gbps Type A (Rear)2x USB 5Gbps Type A (Front)1x USB 5Gbps Type C (Front)
LAN
Realtek® RTL8111H 1Gbps LAN
Internal IO
1x Power Connector(ATX_PWR)1x Power Connector(CPU_PWR)1x CPU Fan1x System Fan2x Front Panel (JFP)1x Chassis Intrusion (JCI)1x Front Audio (JAUD)1x Com Port (JCOM)3x Addressable V2 RGB LED connector (JARGB_V2)1x RGB LED connector(JRGB)1x TPM pin header(Support TPM 2.0)4x USB 2.0 ports2x USB 5Gbps Type A ports1x USB 5Gbps Type C ports
LED FEATURE
4x EZ Debug LED
BACK PANEL PORTS
HDMIDisplayPortKeyboard / MouseUSB 5Gbps Type-ALAN PortAudio connectorsUSB 2.0USB 5Gbps Type-A
OPERATING SYSTEM
Support for Windows® 11 64-bit, Windows® 10 64-bit
BOX CONTENT
PCB Info
mATX220mmx243.84mm
Гаранция: 36 месеца
