CPU
LGA1851 socket, supports Intel® Core Ultra Processors, L3 cache varies by CPU

Chipset
Intel® Z890 Express Chipset

Memory
4 x DDR5 DIMM slots, Dual Channel, up to 256 GB, up to DDR5 9466+ MT/s (OC), supports Non-ECC Un-buffered DIMM, CUDIMM and Intel® XMP

Onboard Graphics
Integrated Graphics Processor support, 1 x DisplayPort 2.1 up to 4096 x 2304 @ 60 Hz, HDCP 2.3

Audio
Realtek® Audio CODEC, High Definition Audio, 2/4/5.1-channel

LAN
Realtek® 2.5GbE LAN chip (2.5 Gbps / 1 Gbps / 100 Mbps)

Expansion Slots
CPU: 1 x PCI Express x16, PCIe 5.0 x16; Chipset: 2 x PCI Express x16, PCIe 4.0 x4

Storage Interface
CPU: 1 x M. 2 M2A_CPU, Socket 3, M key, type 25110/22110/2580/2280, PCIe 5.0 x4/x2; 1 x M. 2 M2B_CPU, type 22110/2280, PCIe 4.0 x4/x2; Chipset: 1 x M. 2 M2Q_SB, type 22110/2280, PCIe 4.0 x4/x2; 1 x M. 2 M2M_SB, type 22110/2280, SATA and PCIe 4.0 x4/x2; 4 x SATA 6Gb/s

RAID
NVMe: RAID 0, RAID 1, RAID 5, RAID 10; SATA: RAID 0, RAID 1, RAID 5, RAID 10

USB
Chipset: 1 x USB Type-C® USB 3.2 Gen 2 rear port, 1 x USB Type-C® USB 3.2 Gen 1 via internal header, 1 x USB 3.2 Gen 2 Type-A rear port, 6 x USB 3.2 Gen 1 (4 rear, 2 via internal header); Chipset + 2 USB 2.0 Hubs: 8 x USB 2.0/1.1 (4 rear, 4 via internal headers)

Internal I/O Connectors
1 x 24-pin ATX main power connector, 2 x 8-pin ATX 12V power connectors, 1 x CPU fan header, 1 x CPU fan/water cooling pump header, 3 x system fan headers, 1 x system fan/water cooling pump header, 3 x addressable RGB Gen2 LED strip headers, 1 x RGB LED strip header, 4 x M. 2 Socket 3 connectors, 4 x SATA 6Gb/s connectors, 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C® USB 3.2 Gen 1 header, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 2 x Thunderbolt add-in card connectors, 1 x Trusted Platform Module header, 1 x serial port header, 1 x reset jumper, 1 x Clear CMOS jumper

Back Panel Connectors
1 x Reset button, 1 x Power button, 1 x Clear CMOS button, 1 x Q-Flash Plus button, 1 x DisplayPort, 1 x USB Type-C® USB 3.2 Gen 2, 1 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1, 4 x USB 2.0/1.1, 1 x RJ-45, 3 x audio jacks

I/O Controller
iTE® I/O Controller Chip

H/W Monitoring
Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control

BIOS
1 x 256 Mbit flash, licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features
GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup

Bundled Software
Norton® Internet Security (OEM version)

Operating System
Windows 11 64-bit, Windows 10 64-bit; Intel® NPU driver and Intel® 800 Platform Performance Package Installer supported only on Windows 11

Form Factor
ATX, 30.5 x 24.4 cm

Гаранция: 36 месеца

Продукт известен още и като Z 890 D PLUS, Z890DPLUS
